Преобразователи переменного и постоянного тока
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - Вход | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Напряжение - Выход 5 | Напряжение - Выход 6 | Ток - Выход 1 | Ток - Выход 2 | Ток - Выход 3 | Ток - Выход 4 | Ток - Выход 5 | Ток - Выход 6 | Мощность (Вт) | Применение | Напряжение - Изоляция | Эффективность | Рабочая температура | Особенности | Тип крепления | Размер/измерение | Сертифицирующее агентство |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1010574CHREL-185-1001 CH |
50 |
|
Технический лист |
REL-185 (185W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 2.5V | - | - | - | - | - | 37 A | - | - | - | - | - | 185W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.23" L x 4.36" W x 1.74" H (183.6mm x 110.7mm x 44.2mm) | CE, cURus, TUV, UKCA |
|
|
1010577CHREL-185-1004 CH |
50 |
|
Технический лист |
REL-185 (185W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 15.4 A | - | - | - | - | - | 185W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 7.23" L x 4.36" W x 1.74" H (183.6mm x 110.7mm x 44.2mm) | CE, cURus, TUV, UKCA |
|
1010289SRP-100-3001 |
29 |
|
- |
SRP-100 (100W) | Box | Active | Chassis | 3 | 100 ~ 240 VAC | 5V | 12V | - | -12V | - | - | 12 A | 4 A | 1 A | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.50" H (127.0mm x 83.8mm x 38.1mm) | CE, cURus, TUV, UKCA |
|
1010024CHCOSRW-65-4005 CHCO |
50 |
|
Технический лист |
SRW-65 (65W) | Box | Not For New Designs | Enclosed | 4 | 100 ~ 240 VAC | 5V | 24V | 12V | -5V | - | - | 5 A | 1 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 76% | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.23" L x 4.25" W x 1.65" H (158.2mm x 108.0mm x 41.9mm) | CE, TUV, UKCA |
|
|
1010020CHCOSRW-65-4001 CHCO |
50 |
|
Технический лист |
SRW-65 (65W) | Box | Not For New Designs | Enclosed | 4 | 100 ~ 240 VAC | 5V | -5V | 12V | -12V | - | - | 5 A | 3 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 76% | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.23" L x 4.25" W x 1.65" H (158.2mm x 108.0mm x 41.9mm) | CE, TUV, UKCA |
|
|
1010196CHCOSRW-65-4007 CHCO |
50 |
|
Технический лист |
SRW-65 (65W) | Box | Not For New Designs | Enclosed | 4 | 100 ~ 240 VAC | 5V | 26V | 15V | -15V | - | - | 5 A | 1 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 76% | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.23" L x 4.25" W x 1.65" H (158.2mm x 108.0mm x 41.9mm) | CE, TUV, UKCA |
|
|
1010022CHCOSRW-65-4003 CHCO |
50 |
|
Технический лист |
SRW-65 (65W) | Box | Not For New Designs | Enclosed | 4 | 100 ~ 240 VAC | 5V | 24V | 12V | -12V | - | - | 5 A | 1 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 76% | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.23" L x 4.25" W x 1.65" H (158.2mm x 108.0mm x 41.9mm) | CE, TUV, UKCA |
|
|
1010021CHCOSRW-65-4002 CHCO |
50 |
|
Технический лист |
SRW-65 (65W) | Box | Not For New Designs | Enclosed | 4 | 100 ~ 240 VAC | 5V | 12V | 12V | -12V | - | - | 5 A | 1 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 76% | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.23" L x 4.25" W x 1.65" H (158.2mm x 108.0mm x 41.9mm) | CE, TUV, UKCA |
|
|
1010238CHCOSRW-65-4008 CHCO |
50 |
|
Технический лист |
SRW-65 (65W) | Box | Not For New Designs | Enclosed | 4 | 100 ~ 240 VAC | 5V | 24V | 12V | -12V | - | - | 5 A | 1 A | 2 A | 2 A | - | - | 80W | Industrial, ITE (Commercial) | - | 76% | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.23" L x 4.25" W x 1.65" H (158.2mm x 108.0mm x 41.9mm) | CE, TUV, UKCA |
|
|
1010023CHCOSRW-65-4004 CHCO |
50 |
|
Технический лист |
SRW-65 (65W) | Box | Not For New Designs | Enclosed | 4 | 100 ~ 240 VAC | 5V | -5V | 15V | -15V | - | - | 5 A | 3 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 76% | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.23" L x 4.25" W x 1.65" H (158.2mm x 108.0mm x 41.9mm) | CE, TUV, UKCA |
|
|
1010025CHCOSRW-65-4006 CHCO |
50 |
|
Технический лист |
SRW-65 (65W) | Box | Not For New Designs | Enclosed | 4 | 100 ~ 240 VAC | 5V | 24V | 15V | -15V | - | - | 5 A | 1 A | 2 A | 2 A | - | - | 65W | Industrial, ITE (Commercial) | - | 76% | 0°C ~ 50°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.23" L x 4.25" W x 1.65" H (158.2mm x 108.0mm x 41.9mm) | CE, TUV, UKCA |
|
PMK150S-24UAC/DC CONVERTER 24V 151W |
61 |
|
Технический лист |
PMK150U (151W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 151W | ITE (Commercial) | 4.242 kV | 75% | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 5.50" L x 3.17" W x 1.60" H (139.7mm x 80.5mm x 40.6mm) | cURus |
|
GPFM115-12AC/DC CONVERTER 12V 115W |
0 |
|
Технический лист |
GPFM115 (115W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 6.7 A | - | - | - | - | - | 115W | Medical | - | 81% | 0°C ~ 50°C | Adjustable Output, PFC, Remote Sense, Universal Input | Chassis Mount | 5.25" L x 3.30" W x 1.50" H (133.4mm x 83.8mm x 38.1mm) | CE, cURus, TUV |
|
1010281CHCOSRW-100-1004 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 15V | - | - | - | - | - | 6.7 A | - | - | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
|
|
1010278CHCOSRW-100-1001 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 3.3V | - | - | - | - | - | 20 A | - | - | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
|
|
1010284CHCOSRW-100-1007 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 48V | - | - | - | - | - | 2.1 A | - | - | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
|
|
1010283CHCOSRW-100-1006 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 28V | - | - | - | - | - | 3.6 A | - | - | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
|
|
1010282CHCOSRW-100-1005 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 24V | - | - | - | - | - | 4.2 A | - | - | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
|
|
1010367CHCOSRW-100-1008 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 40V | - | - | - | - | - | 2.5 A | - | - | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
|
|
1010279CHCOSRW-100-1002 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 5V | - | - | - | - | - | 20 A | - | - | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
