Преобразователи переменного и постоянного тока
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - Вход | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Напряжение - Выход 5 | Напряжение - Выход 6 | Ток - Выход 1 | Ток - Выход 2 | Ток - Выход 3 | Ток - Выход 4 | Ток - Выход 5 | Ток - Выход 6 | Мощность (Вт) | Применение | Напряжение - Изоляция | Эффективность | Рабочая температура | Особенности | Тип крепления | Размер/измерение | Сертифицирующее агентство |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1011196CHCOREL-70-1005 CHCO |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 15V | - | - | - | - | - | 4.7 A | - | - | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1011195CHCOREL-70-1004 CHCO |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 5.8 A | - | - | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1011198CHCOREL-70-1007 CHCO |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 28V | - | - | - | - | - | 2.5 A | - | - | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1011199CHCOREL-70-1008 CHCO |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 48V | - | - | - | - | - | 1.5 A | - | - | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1011194CHCOREL-70-1003 CHCO |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 5V | - | - | - | - | - | 14 A | - | - | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
VGS-75-24AC/DC CONVERTER 24V 75W |
0 |
|
Технический лист |
VGS-75 (76.8W) | Bulk | Obsolete | Enclosed | 1 | 88 ~ 264 VAC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 75W | ITE (Commercial) | 4.242 kV | 88% | -20°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 5.10" L x 3.84" W x 1.48" H (129.5mm x 97.5mm x 37.5mm) | CB Scheme, EN, IEC, SIQ, TUV, UL |
|
1011212CHREL-70-3003 CH |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Chassis | 3 | 85 ~ 264 VAC | 5.1V | 7.5V | - | -7.5V | - | - | 6 A | 2 A | 2 A | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1011211CHREL-70-3002 CH |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Chassis | 3 | 85 ~ 264 VAC | 5V | 15V | - | -15V | - | - | 6 A | 2 A | 2 A | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1011214CHREL-70-3005 CH |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Chassis | 3 | 85 ~ 264 VAC | 5V | 18V | - | 18V | - | - | 5 A | 2 A | 2 A | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1011213CHREL-70-3004 CH |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Chassis | 3 | 85 ~ 264 VAC | 3.3V | 7V | 12V | - | - | - | 6 A | 5 A | 2 A | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1011210CHREL-70-3001 CH |
50 |
|
Технический лист |
REL-70 (70W) | Box | Active | Chassis | 3 | 85 ~ 264 VAC | 5V | 12V | - | -12V | - | - | 6 A | 2 A | 2 A | - | - | - | 70W | Industrial, ITE (Commercial), Laboratory, Medical | - | 78% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.79" L x 2.62" W x 1.48" H (121.6mm x 66.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
LDA100W-48-YAC/DC CONVERTER 48V 96W |
57 |
|
Технический лист |
LDA (100W) | Box | Obsolete | Open Frame | 1 | 85 ~ 132 VAC, 170 ~ 264 VAC | 48V | - | - | - | - | - | 2 A | - | - | - | - | - | 96W | ITE (Commercial) | 3 kV | 82% | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.44" W x 1.38" H (222.0mm x 62.0mm x 35.0mm) | cCSAus, CE, cURus, TUV |
|
1011247CHCOGRN-110-2001 CHCO |
50 |
|
Технический лист |
GRN-110 (110W) | Box | Active | Enclosed | 2 | 85 ~ 264 VAC | 5V | 24V | - | - | - | - | 12 A | 3 A | - | - | - | - | 132W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.25" L x 3.25" W x 1.50" H (133.4mm x 82.6mm x 38.1mm) | CE, cURus, TUV, UKCA |
|
1011378CHGRN-110-2002 OVP CH |
50 |
|
Технический лист |
GRN-110 (110W) | Box | Active | Chassis | 2 | 85 ~ 264 VAC | 5V | 12V | - | - | - | - | 12 A | 5 A | - | - | - | - | 120W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.25" L x 3.25" W x 1.50" H (133.4mm x 82.6mm x 38.1mm) | CE, cURus, TUV, UKCA |
|
|
1011248CHCOGRN-110-2002 CHCO |
50 |
|
Технический лист |
GRN-110 (110W) | Box | Active | Enclosed | 2 | 85 ~ 264 VAC | 5V | 12V | - | - | - | - | 12 A | 5 A | - | - | - | - | 120W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.25" L x 3.25" W x 1.50" H (133.4mm x 82.6mm x 38.1mm) | CE, cURus, TUV, UKCA |
|
|
1011249CHCOGRN-110-2003 CHCO |
50 |
|
Технический лист |
GRN-110 (110W) | Box | Active | Enclosed | 2 | 85 ~ 264 VAC | 12V | -12V | - | - | - | - | 5 A | 5 A | - | - | - | - | 110W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.25" L x 3.25" W x 1.50" H (133.4mm x 82.6mm x 38.1mm) | CE, cURus, TUV, UKCA |
|
|
1011250CHCOGRN-110-2004 CHCO |
50 |
|
Технический лист |
GRN-110 (110W) | Box | Active | Enclosed | 2 | 85 ~ 264 VAC | 15V | -15V | - | - | - | - | 4 A | 4 A | - | - | - | - | 110W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.25" L x 3.25" W x 1.50" H (133.4mm x 82.6mm x 38.1mm) | CE, cURus, TUV, UKCA |
|
|
1011380CHGRN-110-2004 OVP CH |
50 |
|
Технический лист |
GRN-110 (110W) | Box | Active | Chassis | 2 | 85 ~ 264 VAC | 15V | -15V | - | - | - | - | 4 A | 4 A | - | - | - | - | 120W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.25" L x 3.25" W x 1.50" H (133.4mm x 82.6mm x 38.1mm) | CE, cURus, TUV, UKCA |
|
|
1011379CHGRN-110-2003 OVP CH |
50 |
|
Технический лист |
GRN-110 (110W) | Box | Active | Chassis | 2 | 85 ~ 264 VAC | 12V | -12V | - | - | - | - | 5 A | 5 A | - | - | - | - | 120W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.25" L x 3.25" W x 1.50" H (133.4mm x 82.6mm x 38.1mm) | CE, cURus, TUV, UKCA |
|
|
1011377CHGRN-110-2001 OVP CH |
50 |
|
Технический лист |
GRN-110 (110W) | Box | Active | Chassis | 2 | 85 ~ 264 VAC | 5V | 24V | - | - | - | - | 12 A | 3 A | - | - | - | - | 132W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.25" L x 3.25" W x 1.50" H (133.4mm x 82.6mm x 38.1mm) | CE, cURus, TUV, UKCA |
