DC-DC Преобразователи
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Особенности | Рабочая температура | Эффективность | Марка | Квалификация | Тип крепления | Размер/измерение | Устройство поставщика Упаковка | Функции управления | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PTB78560CAHDC DC CONVERTER 9-13.2V 30W |
166 |
|
Технический лист |
PTB78560 (30W) | 11-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 18V | 60V | 9 ~ 13.2V | - | - | - | 2.5A | 30 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C | 88% | - | - | Through Hole | 2.05" L x 1.05" W x 0.39" H (52.1mm x 26.7mm x 10.0mm) | - | - | - | - |
.jpg)
|
LTM4647IYDC DC CONVERTER 0.6-1.8V |
60 |
|
Технический лист |
µModule® | 77-BBGA Module | Tray | Active | Non-Isolated PoL Module | 1 | 4.7V | 15V | 0.6 ~ 1.8V | - | - | - | 30A | - | - | ITE (Commercial) | OCP, OVP, UVLO | -40°C ~ 125°C | 87% | - | - | Surface Mount | 0.59" L x 0.35" W x 0.20" H (15.0mm x 9.0mm x 5.0mm) | 77-BGA (15x9) | - | - | - |
|
PXD-M30-24WS12DC DC CONVERTER 12V 30W |
131 |
|
Технический лист |
PXD-M (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 12V | - | - | - | 2.5A | 30 W | 5 kV | ITE (Commercial), Medical | Adjustable Output | -40°C ~ 105°C (With Derating) | 89% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | CE | - |
|
|
PXD-M30-24WS15DC DC CONVERTER 15V 30W |
42 |
|
Технический лист |
PXD-M (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 15V | - | - | - | 2A | 30 W | 5 kV | ITE (Commercial), Medical | Adjustable Output | -40°C ~ 105°C (With Derating) | 90.5% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | CE | - |
|
AEE02H36-LDC DC CONVERTER 24V 50W |
167 |
|
Технический лист |
AEE (50W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 75V | 24V | - | - | - | 2.08A | 50 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP | -40°C ~ 85°C | 92% | - | - | Through Hole | 2.00" L x 1.00" W x 0.43" H (50.8mm x 25.4mm x 11.0mm) | - | - | - | - |
|
LTM4630IY#PBFDC DC CNVRTR 0.6-1.8V 0.6-1.8V |
121 |
|
Технический лист |
µModule® | 144-BBGA Module | Tray | Active | Non-Isolated PoL Module | 2 | 4.5V | 15V | 0.6 ~ 1.8V | 0.6 ~ 1.8V | - | - | 18A, 18A | - | - | ITE (Commercial) | OCP, OVP | -40°C ~ 125°C | - | - | - | Surface Mount | 0.63" L x 0.63" W x 0.17" H (16.0mm x 16.0mm x 4.4mm) | 144-BGA (16x16) | - | - | - |
|
VTM48EH060T020A00DC DC CONVERTER 6V 120W |
434 |
|
Технический лист |
VI Chip® VTM® | Module | Tray | Active | Voltage Transformation Module | 1 | 26V | 55V | 6V | - | - | - | 20A | 120 W | 2.25 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP | -40°C ~ 125°C | 94.1% | - | - | Surface Mount | 0.87" L x 0.65" W x 0.26" H (22.0mm x 16.5mm x 6.7mm) | - | - | - | - |
|
LTM4677EY#PBFDC DC CNVRTR 0.5-1.8V 0.5-1.8V |
375 |
|
Технический лист |
µModule® | 144-BBGA Module | Tray | Active | Isolated Module | 2 | 4.5V | 16V | 0.5 ~ 1.8V | 0.5 ~ 1.8V | - | - | 18A, 18A | - | - | ITE (Commercial) | Remote On/Off, OTP, OVP, SCP, UVLO | -40°C ~ 125°C | - | - | - | Surface Mount | 0.63" L x 0.63" W x 0.20" H (16.0mm x 16.0mm x 5.0mm) | 144-BGA (16x16) | - | - | - |
|
LTM4630AIV#PBFDC DC CNVRTR 0.6-5.3V 0.6-5.3V |
805 |
|
Технический лист |
µModule® | 144-BLGA Module | Tray | Active | Non-Isolated PoL Module | 2 | 4.5V | 15V | 0.6 ~ 5.3V | 0.6 ~ 5.3V | - | - | 18A, 18A | - | - | ITE (Commercial) | OCP, OVP | -40°C ~ 125°C | - | - | - | Surface Mount | 0.63" L x 0.63" W x 0.17" H (16.0mm x 16.0mm x 4.4mm) | 144-LGA (16x16) | - | - | - |
|
JTL6024D15DC DC CONVERTER +/-15V 60W |
206 |
|
Технический лист |
JTL60 (60W) | 6-DIP Module | Tube | Active | Isolated Module | 2 | 9V | 36V | 15V | -15V | - | - | 2A, 2A | 60 W | 1.6 kV | ITE (Commercial) | Remote On/Off, OVP, SCP | -40°C ~ 85°C | 91% | - | - | Through Hole | 2.00" L x 1.00" W x 0.45" H (50.8mm x 25.4mm x 11.4mm) | - | Enable, Active High | - | 62368-1 |
|
CHB75-12S24DC DC CONVERTER 24V 75W |
52 |
|
Технический лист |
CHB75 (75W) | Half Brick | Tray | Active | Isolated Module | 1 | 9V | 18V | 24V | - | - | - | 3.13A | 75 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 100°C (With Derating) | 87% | - | - | Through Hole | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) | Half Brick | Enable, Active High | CE, cURus | 60950-1 |
|
SIP90DC DC CONVERTER 25-90V 100MW |
63 |
|
Технический лист |
XP EMCO - SIP (1W) | 5-SIP Module | Bulk | Active | High Voltage - Non-Isolated Module | 1 | 3V | 6.7V | 25 ~ 90V | - | - | - | 1mA | 100 mW | - | ITE (Commercial) | - | -20°C ~ 70°C | - | - | - | Through Hole | 1.15" L x 0.16" W x 0.55" H (29.2mm x 4.1mm x 14.0mm) | - | - | - | - |
|
BWR-15/670-D12A-CDC DC CONVERTER +/-15V 20W |
113 |
|
Технический лист |
BWR (10W) | 8-DIP Module, 7 Leads | Tube | Active | Isolated Module | 2 | 9V | 36V | 15V | -15V | - | - | 670mA, 670mA | 20 W | 1 kV | ITE (Commercial) | - | -40°C ~ 100°C | 83% | - | - | Through Hole | 2.00" L x 2.00" W x 0.45" H (50.8mm x 50.8mm x 11.4mm) | - | - | - | - |
|
THM 20-2411WIDC DC CONVERTER 5V 20W |
31 |
|
Технический лист |
THM 20WI (20W) | 5-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 5V | - | - | - | 4A | 20 W | 5 kV | Medical | OCP, OTP, OVP, SCP | -40°C ~ 80°C (With Derating) | 87% | - | - | Through Hole | 1.60" L x 1.00" W x 0.40" H (40.6mm x 25.4mm x 10.2mm) | - | - | - | - |
|
LTM4601AHVMPV#PBFDC DC CONVERTER 0.6-5V |
33 |
|
Технический лист |
µModule® | 133-BLGA Module | Tray | Active | Non-Isolated PoL Module | 1 | 4.5V | 28V | 0.6 ~ 5V | - | - | - | 12A | - | - | ITE (Commercial) | OVP, SCP, UVLO | -55°C ~ 125°C | 95% | - | - | Surface Mount | 0.59" L x 0.59" W x 0.11" H (15.0mm x 15.0mm x 2.8mm) | 133-LGA (15x15) | - | - | - |
|
THM 30-2413WIDC DC CONVERTER 15V 30W |
182 |
|
Технический лист |
THM 30WI (30W) | 5-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 15V | - | - | - | 2A | 30 W | 5 kV | Medical | OCP, OTP, OVP, SCP | -40°C ~ 80°C (With Derating) | 89% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | - | - |
|
THM 30-2412WIDC DC CONVERTER 12V 30W |
35 |
|
Технический лист |
THM 30WI (30W) | 5-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 12V | - | - | - | 2.5A | 30 W | 5 kV | Medical | OCP, OTP, OVP, SCP | -40°C ~ 80°C (With Derating) | 89% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | - | - | - |
|
TEN 40-2415WIRDC DC CONVERTER 24V 40W |
1,115 |
|
Технический лист |
TEN 40WIR (40W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 24V | - | - | - | 1.666A | 40 W | 1.6 kV | ITE (Commercial), Railway | Remote On/Off, OCP, OVP, SCP, UVLO | -40°C ~ 85°C (With Derating) | 91% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | Module | - | - | - |
|
TEN 40-2412WIRDC DC CONVERTER 12V 40W |
335 |
|
Технический лист |
TEN 40WIR (40W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 12V | - | - | - | 3.333A | 40 W | 1.6 kV | ITE (Commercial), Railway | Remote On/Off, OCP, OVP, SCP, UVLO | -40°C ~ 85°C (With Derating) | 92% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | Module | - | - | - |
|
TEN 40-2413WIRDC DC CONVERTER 15V 40W |
125 |
|
Технический лист |
TEN 40WIR (40W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 36V | 15V | - | - | - | 2.666A | 40 W | 1.6 kV | ITE (Commercial), Railway | Remote On/Off, OCP, OVP, SCP, UVLO | -40°C ~ 85°C (With Derating) | 92% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | Module | - | - | - |
