Преобразователи переменного и постоянного тока
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - Вход | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Напряжение - Выход 5 | Напряжение - Выход 6 | Ток - Выход 1 | Ток - Выход 2 | Ток - Выход 3 | Ток - Выход 4 | Ток - Выход 5 | Ток - Выход 6 | Мощность (Вт) | Применение | Напряжение - Изоляция | Эффективность | Рабочая температура | Особенности | Тип крепления | Размер/измерение | Сертифицирующее агентство |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1010507CHREL-150-4007 CH |
50 |
|
Технический лист |
REL-150 (150W) | Box | Active | Chassis | 4 | 85 ~ 264 VAC | 5V | 24V | 15V | -15V | - | - | 15 A | 3 A | 2 A | 2 A | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1010502CHREL-150-4002 CH |
50 |
|
Технический лист |
REL-150 (150W) | Box | Active | Chassis | 4 | 85 ~ 264 VAC | 5V | 3.3V | 12V | -12V | - | - | 15 A | 8 A | 2 A | 2 A | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1010616CHREL-150-4009 CH |
50 |
|
Технический лист |
REL-150 (150W) | Box | Active | Chassis | 4 | 85 ~ 264 VAC | 24V | 10V | 6V | -6V | - | - | 2.3 A | 1 A | 1.6 A | 310 mA | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1010504CHREL-150-4004 CH |
50 |
|
Технический лист |
REL-150 (150W) | Box | Active | Chassis | 4 | 85 ~ 264 VAC | 5V | -5V | 12V | -12V | - | - | 15 A | 8 A | 2 A | 2 A | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1010503CHREL-150-4003 CH |
50 |
|
Технический лист |
REL-150 (150W) | Box | Active | Chassis | 4 | 85 ~ 264 VAC | 5V | 3.3V | 15V | -15V | - | - | 15 A | 8 A | 2 A | 2 A | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1010837CHREL-150-4011 CH |
50 |
|
Технический лист |
REL-150 (150W) | Box | Active | Chassis | 4 | 85 ~ 264 VAC | 3.5V | 5.2V | 12.5V | 13.3V | - | - | 10 A | 9 A | 1 A | 3 A | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1010501CHREL-150-4001 CH |
50 |
|
Технический лист |
REL-150 (150W) | Box | Active | Chassis | 4 | 85 ~ 264 VAC | 3.3V | 5V | 12V | -12V | - | - | 15 A | 8 A | 2 A | 2 A | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
|
1010838CHREL-150-4012 CH |
50 |
|
Технический лист |
REL-150 (150W) | Box | Active | Chassis | 4 | 85 ~ 264 VAC | 3.3V | 5V | 14V | -14V | - | - | 15 A | 8 A | 2 A | 2 A | - | - | 150W | Industrial, ITE (Commercial), Laboratory, Medical | - | 82% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA |
|
1010847NXT-225-1006 |
60 |
|
Технический лист |
NXT-225 (225W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 24V | - | - | - | - | - | 9.4 A | - | - | - | - | - | 225W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.50" H (127.0mm x 76.2mm x 38.0mm) | CE, cURus, TUV, UKCA |
|
|
1010844NXT-225-1003 |
50 |
|
Технический лист |
NXT-225 (225W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 5V | - | - | - | - | - | 45 A | - | - | - | - | - | 225W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.50" H (127.0mm x 76.2mm x 38.0mm) | CE, cURus, TUV, UKCA |
|
|
1010848NXT-225-1007 |
50 |
|
Технический лист |
NXT-225 (225W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 28V | - | - | - | - | - | 8 A | - | - | - | - | - | 225W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.50" H (127.0mm x 76.2mm x 38.0mm) | CE, cURus, TUV, UKCA |
|
|
1010842NXT-225-1001 |
50 |
|
Технический лист |
NXT-225 (225W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 2.5V | - | - | - | - | - | 53 A | - | - | - | - | - | 225W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.50" H (127.0mm x 76.2mm x 38.0mm) | CE, cURus, TUV, UKCA |
|
|
1010845NXT-225-1004 |
38 |
|
Технический лист |
NXT-225 (225W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 12V | - | - | - | - | - | 18.8 A | - | - | - | - | - | 225W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.50" H (127.0mm x 76.2mm x 38.0mm) | CE, cURus, TUV, UKCA |
|
|
1010843NXT-225-1002 |
26 |
|
Технический лист |
NXT-225 (225W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 3.3V | - | - | - | - | - | 53 A | - | - | - | - | - | 225W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.50" H (127.0mm x 76.2mm x 38.0mm) | CE, cURus, TUV, UKCA |
|
1010274CHCOSRW-100-3001 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 3 | 100 ~ 240 VAC | 5V | 12V | - | -12V | - | - | 10 A | 4 A | 1 A | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
|
|
1010275CHCOSRW-100-3002 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 3 | 100 ~ 240 VAC | 5V | 15V | - | -15V | - | - | 10 A | 3 A | 1 A | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
|
|
1010460CHCOSRW-100-3004 CHCO |
50 |
|
Технический лист |
SRW-100 (100W) | Box | Active | Enclosed | 3 | 100 ~ 240 VAC | 3.3V | 5.8V | - | -48V | - | - | 5 A | 3 A | 1 A | - | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 76% | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.75" H (127.0mm x 83.8mm x 44.5mm) | CE, cURus, TUV, UKCA |
|
1010895CHNXT-175-1002,RE STBY CH |
50 |
|
Технический лист |
NXT-175 (175W) | Box | Active | Chassis | 1 | 100 ~ 240 VAC | 3.3V | - | - | - | - | - | 35 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.24" L x 3.12" W x 1.53" H (133.1mm x 79.2mm x 38.9mm) | CE, cURus, TUV, UKCA |
|
|
1010901CHNXT-175-1008,RE STBY CH |
50 |
|
Технический лист |
NXT-175 (175W) | Box | Active | Chassis | 1 | 100 ~ 240 VAC | 48V | - | - | - | - | - | 3.6 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.24" L x 3.12" W x 1.53" H (133.1mm x 79.2mm x 38.9mm) | CE, cURus, TUV, UKCA |
|
|
1010900CHNXT-175-1007,RE STBY CH |
50 |
|
Технический лист |
NXT-175 (175W) | Box | Active | Chassis | 1 | 100 ~ 240 VAC | 28V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 85% | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.24" L x 3.12" W x 1.53" H (133.1mm x 79.2mm x 38.9mm) | CE, cURus, TUV, UKCA |
