Твердотельные реле (SSR)
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип крепления | Схема | Тип выхода | Напряжение - Вход | Напряжение - нагрузка | Ток нагрузки | Сопротивление в открытом состоянии (макс.) | Тип вывода | Рабочая температура | Устройство поставщика Упаковка | Сертифицирующее агентство | Марка | Квалификация |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PCS34-D-240A-80ZYLSSR RELAY 80A 48~280VAC SCREW TE |
15 |
|
Технический лист |
PCS34 | Tray | Active | Chassis Mount | SPST-NO (1 Form A) | AC, Zero Cross | 4 ~ 32VDC | 48 V ~ 530 V | 80 A | - | Screw Terminal | -30°C ~ 80°C | Hockey Puck | cURus | - | - |
|
|
PCS34-D-240A-80RYLSSR RELAY 80A 48~280VAC SCREW TE |
15 |
|
Технический лист |
PCS34 | Tray | Active | Chassis Mount | SPST-NO (1 Form A) | AC | 4 ~ 32VDC | 48 V ~ 530 V | 80 A | - | Screw Terminal | -30°C ~ 80°C | Hockey Puck | cURus | - | - |
|
DR24B06SSR RELAY SPST-NO 6A 24-280V |
10 |
|
Технический лист |
DR | Bulk | Active | DIN Rail | SPST-NO (1 Form A) | AC, Zero Cross | 90 ~ 140VAC | 24 V ~ 280 V | 6 A | - | Screw Terminal | -20°C ~ 40°C | - | CE, cULus | - | - |
|
|
SRP1-CBDZH-025NW-NSRP1-CB |
18 |
|
Технический лист |
SRP1-CB | Bulk | Active | Chassis Mount | SPST-NO (1 Form A) | AC, Zero Cross | 4 ~ 32VDC | 48 V ~ 600 V | 25 A | 6.3 mOhms | Screw Terminal | -40°C ~ 70°C | - | CE, cURus, IEC | - | - |
|
CWA2425ESSR RELAY SPST-NO 25A 24-280V |
20 |
|
Технический лист |
CW | Bulk | Active | Chassis Mount | SPST-NO (1 Form A) | AC, Zero Cross | 18 ~ 36VAC | 24 V ~ 280 V | 25 A | - | Screw Terminal | -40°C ~ 80°C | - | CE, CSA, cURus, TUV | - | - |
|
|
2900383SSR RELAY SPST-NO 1A 12-300V |
14 |
|
Технический лист |
PLC-OPT | Bulk | Active | DIN Rail | SPST-NO (1 Form A) | DC | 24VDC | 12 V ~ 300 V | 1 A | - | Screw Terminal | -25°C ~ 60°C | - | CE, DNV, UKCA | - | - |
|
84134017SSR RELAY SPST-NO 25A 24-280V |
17 |
|
- |
GN | Bulk | Active | Chassis Mount | SPST-NO (1 Form A) | AC, Zero Cross | 3 ~ 32VDC | 24 V ~ 280 V | 25 A | - | Quick Connect - 0.250" (6.3mm) | -40°C ~ 80°C | - | CE, CSA, cURus, TUV | - | - |
|
|
PCS34-A-480A-100ZLSSR RELAY 100A 48~530VAC SCREW T |
15 |
|
Технический лист |
PCS34 | Tray | Active | Chassis Mount | SPST-NO (1 Form A) | AC, Zero Cross | 90 ~ 280VAC | 48 V ~ 530 V | 100 A | - | Screw Terminal | -30°C ~ 80°C | Hockey Puck | cURus | - | - |
|
|
SRP1-CBDRH-025NW-NSRP1-CB |
20 |
|
Технический лист |
SRP1-CB | Bulk | Active | Chassis Mount | SPST-NO (1 Form A) | AC | 4 ~ 32VDC | 48 V ~ 600 V | 25 A | 6.3 mOhms | Screw Terminal | -40°C ~ 70°C | - | CE, cURus, IEC | - | - |
|
HD4812SSR RELAY SPST-NO 12A 48-530V |
17 |
|
Технический лист |
HD48 | Bulk | Active | Chassis Mount | SPST-NO (1 Form A) | AC, Zero Cross | 3 ~ 32VDC | 48 V ~ 530 V | 12 A | - | Screw Terminal | -40°C ~ 80°C | - | CE, CSA, cURus, TUV | - | - |
|
|
SRP1-CRDRL-050TC-NSRP1-CR |
20 |
|
Технический лист |
SRP1-CR | Bulk | Active | Chassis Mount | SPST-NO (1 Form A) | AC | 4 ~ 32VDC | 24 V ~ 240 V | 50 A | 6.3 mOhms | Screw Terminal | -40°C ~ 70°C | - | CE, cURus, IEC | - | - |
|
|
PCS34-A-480A-100ZYLSSR RELAY 100A 48~530VAC SCREW T |
15 |
|
Технический лист |
PCS34 | Tray | Active | Chassis Mount | SPST-NO (1 Form A) | AC, Zero Cross | 90 ~ 280VAC | 48 V ~ 530 V | 100 A | - | Screw Terminal | -30°C ~ 80°C | Hockey Puck | cURus | - | - |
|
2980665SSR RELAY SPST-NO 1A 12-300V |
8 |
|
Технический лист |
PLC-OSC | Bulk | Active | DIN Rail | SPST-NO (1 Form A) | DC | 12VDC | 12 V ~ 300 V | 1 A | - | Screw Terminal | -20°C ~ 60°C | - | EN, IEC | - | - |
|
857-727SSR RELAY SPST-NO 3A 0-30V |
2 |
|
Технический лист |
857 | Box | Active | DIN Rail | SPST-NO (1 Form A) | DC | 115VAC/DC | 0 V ~ 30 V | 3 A | - | Spring Terminal | -20°C ~ 70°C | - | EAC, UL | - | - |
|
|
2900391SSR RELAY SPST-NO 3A 12-140V |
11 |
|
Технический лист |
PLC-OPT | Bulk | Active | DIN Rail | SPST-NO (1 Form A) | DC | 24VDC | 12 V ~ 140 V | 3 A | - | Screw Terminal | -25°C ~ 60°C | - | CE, DNV, UKCA | - | - |
|
84137200SSR RELAY SPST-NO 10A 24-280V |
20 |
|
Технический лист |
GN | Bulk | Active | Chassis Mount | SPST-NO (1 Form A) | AC | 3 ~ 32VDC | 24 V ~ 280 V | 10 A | - | Screw Terminal | -40°C ~ 80°C | - | CE, CSA, cURus, TUV | - | - |
|
A2410-BSSR RELAY SPST-NC 10A 24-280V |
5 |
|
Технический лист |
1 | Bulk | Active | Chassis Mount | SPST-NC (1 Form B) | AC, Zero Cross | 90 ~ 280VAC | 24 V ~ 280 V | 10 A | - | Screw Terminal | -40°C ~ 80°C | - | CE, CSA, TUV, UL | - | - |
|
|
PCS34-D-480A-50RL-HTSSR RELAY 50A 48~530VAC SCREW TE |
4 |
|
Технический лист |
PCS34 | Box | Active | Chassis Mount | SPST-NO (1 Form A) | AC | 4 ~ 32VDC | 48 V ~ 530 V | 50 A | - | Screw Terminal | -30°C ~ 80°C | Hockey Puck with Heat Sink | cURus | - | - |
|
84134011SSR RELAY SPST-NO 25A 24-280V |
20 |
|
Технический лист |
GN | Bulk | Active | Chassis Mount | SPST-NO (1 Form A) | AC, Zero Cross | 90 ~ 280VAC | 24 V ~ 280 V | 25 A | - | Screw Terminal | -40°C ~ 80°C | - | CE, CSA, cURus, TUV | - | - |
|
|
PCS34-D-480A-80RLSSR RELAY 80A 48~530VAC SCREW TE |
15 |
|
Технический лист |
PCS34 | Tray | Active | Chassis Mount | SPST-NO (1 Form A) | AC | 4 ~ 32VDC | 48 V ~ 530 V | 80 A | - | Screw Terminal | -30°C ~ 80°C | Hockey Puck | cURus | - | - |
