DC-DC Преобразователи
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Особенности | Рабочая температура | Эффективность | Марка | Квалификация | Тип крепления | Размер/измерение | Устройство поставщика Упаковка | Функции управления | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AM6O-2412SNZDC DC CONVERTER 12V 6W |
0 |
|
Технический лист |
AM6O-NZ (6W) | - | Bulk | Active | Isolated Module | 1 | 18V | 36V | 12V | - | - | - | 500mA | 6 W | 500 V | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C | 85% | - | - | Through Hole | 1.24" L x 0.71" W x 0.24" H (31.6mm x 18.1mm x 6.1mm) | - | - | - | - |
|
|
AM6O-2405SNZDC DC CONVERTER 5V 6W |
0 |
|
Технический лист |
AM6O-NZ (6W) | - | Bulk | Active | Isolated Module | 1 | 18V | 36V | 5V | - | - | - | 1.2A | 6 W | 500 V | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C | 83% | - | - | Through Hole | 1.24" L x 0.71" W x 0.24" H (31.6mm x 18.1mm x 6.1mm) | - | - | - | - |
|
AM60EW-4812DZDC DC CONVERTER +/-12V 60W |
0 |
|
Технический лист |
AM60EW-Z (60W) | - | Tube | Active | Isolated Module | 2 | 18V | 75V | -12 ~ 12V | -12V | - | - | 2.5A, 2.5A | 60 W | 1.6 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 75°C | 91% | - | - | Through Hole | 2.00" L x 1.00" W x 0.45" H (50.8mm x 25.4mm x 11.5mm) | - | - | CE, cURus, UL | - |
|
AM10G-2409NZDC DC CONVERTER 9V 10W |
0 |
|
Технический лист |
AM10G-NZ (10W) | 8-SIP Module | Tube | Active | Isolated Module | 1 | 18V | 36V | 9V | - | - | - | 1.11A | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 86% | - | - | Through Hole | 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm) | - | - | - | - |
|
AM20E-2409D-NZDC DC CONVERTER +/-9V 20W |
0 |
|
Технический лист |
AM20E-NZ (20W) | - | Tube | Active | Isolated Module | 2 | 18V | 36V | -9 ~ 9V | -9V | - | - | 1.11A, 1.11A | 20 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 88% | - | - | Through Hole | 2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 11.8mm) | - | - | CE | - |
|
|
AM50E-4824S-NZ-KDC DC CONVERTER 24V 50W |
0 |
|
Технический лист |
AM50E-NZ (50W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 36V | 75V | 24V | - | - | - | 2.083A | 50 W | 1.5 kV | ITE (Commercial) | Heat Sink, Remote On/Off | -40°C ~ 65°C (With Derating) | 93% | - | - | Through Hole | 2.00" L x 1.00" W x 0.64" H (50.8mm x 25.4mm x 16.3mm) | - | - | cURus | - |
|
AM1LS-0505D-NZDC DC CONVERTER +/-5V 1W |
0 |
|
Технический лист |
AM1LS-NZ (1W) | SMD | Tube | Active | Isolated Module | 2 | 4.5V | 5.5V | -5 ~ 5V | -5V | - | - | 100mA, 100mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 82% | - | - | Surface Mount | 0.60" L x 0.44" W x 0.28" H (15.2mm x 11.2mm x 7.3mm) | - | - | cULus, cURus | - |
|
AM1LS-0505DH30VZDC DC CONVERTER +/-5V 1W |
0 |
|
Технический лист |
AM1LS-VZ (1W) | SMD | Obsolete | Isolated Module | 2 | 4.5V | 5.5V | -5 ~ 5V | -5V | - | - | 100mA, 100mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 82% | - | - | Surface Mount | 0.60" L x 0.44" W x 0.28" H (15.2mm x 11.4mm x 7.3mm) | - | - | - | - | |
|
AM1L-0305S-NZDC DC CONVERTER 5V 1W |
0 |
|
Технический лист |
AM1L-NZ (1W) | SMD | Tube | Active | Isolated Module | 1 | 3V | 3.6V | 5V | - | - | - | 200mA | 1 W | 1 kV | ITE (Commercial) | - | -40°C ~ 85°C | 71% | - | - | Surface Mount | 0.50" L x 0.30" W x 0.25" H (12.7mm x 7.5mm x 6.3mm) | - | - | CE, cULus, cURus | - |
|
AM10CW-4815D-NZDC DC CONVERTER +/-15V 10W |
0 |
|
Технический лист |
AM10CW-NZ (10W) | - | Obsolete | Isolated Module | 2 | 18V | 75V | -15 ~ 15V | -15V | - | - | 330mA, 330mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 87% | - | - | Through Hole | 1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm) | - | - | CE, cURus, UL | - | |
|
AM6T-1205D-NZDC DC CONVERTER +/-5V 6W |
0 |
|
Технический лист |
AM6T-NZ (6W) | 24-DIP Module | Tube | Active | Isolated Module | 2 | 9V | 18V | -5 ~ 5V | -5V | - | - | 600mA, 600mA | 6 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C | 80% | - | - | Through Hole | 1.26" L x 0.79" W x 0.43" H (32.0mm x 20.0mm x 10.8mm) | - | - | CE | - |
|
AM200QB-4824SH22-NZDC DC CONVERTER 24V 202W |
0 |
|
Технический лист |
AM200QB-NZ (200W) | Quarter Brick | Bulk | Active | Isolated Module | 1 | 18V | 75V | 24V | - | - | - | 8.4A | 200 W | 2.25 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 91% | - | - | Through Hole | 2.43" L x 1.58" W x 0.50" H (61.8mm x 40.2mm x 12.7mm) | Quarter Brick | - | - | - |
|
|
AM10CW-4812S-NZDC DC CONVERTER 12V 10W |
0 |
|
Технический лист |
AM10CW-NZ (10W) | - | Obsolete | Isolated Module | 1 | 18V | 75V | 12V | - | - | - | 830mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 87% | - | - | Through Hole | 1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm) | - | - | CE, cURus, UL | - | |
|
AM1LS-0509SJZDC DC CONVERTER 9V 999MW |
0 |
|
Технический лист |
AM1LS-NZ (1W) | SMD | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 9V | - | - | - | 111mA | 1 mW | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | - | - | Surface Mount | 0.52" L x 0.33" W x 0.29" H (13.2mm x 8.5mm x 7.3mm) | - | - | cULus, cURus | - | |
|
|
AM1LS-0505SJZTRDC DC CONVERTER 5V 1W |
0 |
|
Технический лист |
AM1LS-NZ (1W) | SMD | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 5V | - | - | - | 200mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 82% | - | - | Surface Mount | 0.52" L x 0.33" W x 0.29" H (13.2mm x 8.5mm x 7.3mm) | - | - | cULus, cURus | - | |
|
AM1DS-1215SH30-NZDC DC CONVERTER 15V 1W |
0 |
|
Технический лист |
AM1DS-NZ (1W) | 7-SIP Module | Tube | Active | Isolated Module | 1 | 10.8V | 13.2V | 15V | - | - | - | 67mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 81% | - | - | Through Hole | 0.77" L x 0.24" W x 0.38" H (19.5mm x 6.0mm x 9.6mm) | - | - | cULus, cURus | - |
|
|
AM10CW-4824S-NZDC DC CONVERTER 24V 9.8W |
0 |
|
Технический лист |
AM10CW-NZ (10W) | - | Obsolete | Isolated Module | 1 | 18V | 75V | 24V | - | - | - | 410mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 88% | - | - | Through Hole | 1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm) | - | - | CE, cURus, UL | - | |
|
|
AM6T-1205S-NZDC DC CONVERTER 5V 6W |
0 |
|
Технический лист |
AM6T-NZ (6W) | 24-DIP Module | Obsolete | Isolated Module | 1 | 9V | 18V | 5V | - | - | - | 1.2A | 6 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C | 80% | - | - | Through Hole | 1.26" L x 0.79" W x 0.43" H (32.0mm x 20.0mm x 10.8mm) | - | - | CE | - | |
|
AM1LS-0509SH30VZDC DC CONVERTER 9V 999MW |
0 |
|
Технический лист |
AM1LS-VZ (1W) | SMD | Tube | Active | Isolated Module | 1 | 4.5V | 5.5V | 9V | - | - | - | 111mA | 1 mW | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 83% | - | - | Surface Mount | 0.60" L x 0.33" W x 0.29" H (15.2mm x 8.5mm x 7.3mm) | - | - | - | - |
|
AM15T-1215DZDC DC CONVERTER +/-15V 15W |
0 |
|
Технический лист |
AM15T-Z (15W) | 24-DIP Module | Tube | Active | Isolated Module | 2 | 9V | 18V | -15 ~ 15V | -15V | - | - | 500mA, 500mA | 15 W | 1.6 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 90% | - | - | Through Hole | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) | - | - | CE | - |
