DC-DC Преобразователи
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Особенности | Рабочая температура | Эффективность | Марка | Квалификация | Тип крепления | Размер/измерение | Устройство поставщика Упаковка | Функции управления | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AM1LS-0303S-NZTRDC DC CONVERTER 3.3V 1W |
0 |
|
Технический лист |
AM1LS-NZ (1W) | SMD | Tape & Reel (TR) | Active | Isolated Module | 1 | 2.97V | 3.63V | 3.3V | - | - | - | 303mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 69% | - | - | Surface Mount | 0.50" L x 0.44" W x 0.28" H (12.7mm x 11.2mm x 7.3mm) | - | - | cULus, cURus | - |
|
AM30EW-4824S-NZDC DC CONVERTER 24V 30W |
0 |
|
Технический лист |
AM30EW-NZ (30W) | - | Tube | Active | Isolated Module | 1 | 18V | 75V | 24V | - | - | - | 1.25A | 30 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 80°C | 89% | - | - | Through Hole | 2.00" L x 1.00" W x 0.64" H (50.8mm x 25.4mm x 16.3mm) | - | - | CE, cULus, cURus | - |
|
AM20EWM-2403SH50NZDC DC CONVERTER 3.3V 20W |
0 |
|
Технический лист |
AM20EWM-NZ (20W) | - | Tube | Active | Isolated Module | 1 | 9V | 36V | 3.3V | - | - | - | 5A | 20 W | 5 kV | Medical | Remote On/Off | -40°C ~ 85°C | 85% | - | - | Through Hole | 2.03" L x 1.04" W x 0.47" H (51.5mm x 26.5mm x 12.0mm) | - | - | - | 60601-1 |
|
AM20EW-2409S-NZDC DC CONVERTER 9V 20W |
0 |
|
Технический лист |
AM20EW-NZ (20W) | - | Tube | Active | Isolated Module | 1 | 9V | 36V | 9V | - | - | - | 2.222A | 20 W | 1.5 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C | 89% | - | - | Through Hole | 2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 11.8mm) | - | - | CE, cULus, cURus | - |
|
|
AM1LS-0312S-NZDC DC CONVERTER 12V 1W |
0 |
|
Технический лист |
AM1LS-NZ (1W) | SMD | Tube | Active | Isolated Module | 1 | 2.97V | 3.63V | 12V | - | - | - | 84mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | - | - | Surface Mount | 0.50" L x 0.44" W x 0.28" H (12.7mm x 11.2mm x 7.3mm) | - | - | cULus, cURus | - |
|
AM10G-1205NZDC DC CONVERTER 5V 10W |
0 |
|
Технический лист |
AM10G-NZ (10W) | 8-SIP Module | Tube | Active | Isolated Module | 1 | 9V | 18V | 5V | - | - | - | 2A | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 84% | - | - | Through Hole | 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm) | - | - | - | - |
|
AM10CW-2415D-NZDC DC CONVERTER +/-15V 10W |
0 |
|
Технический лист |
AM10CW-NZ (10W) | - | Tube | Active | Isolated Module | 2 | 9V | 36V | -15 ~ 15V | -15V | - | - | 330mA, 330mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 87% | - | - | Through Hole | 1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm) | - | - | CE, cURus, UL | - |
|
|
AM10CW-2424S-NZDC DC CONVERTER 24V 10W |
0 |
|
Технический лист |
AM10CW-NZ (10W) | - | Obsolete | Isolated Module | 1 | 9V | 36V | 24V | - | - | - | 410mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 88% | - | - | Through Hole | 1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm) | - | - | CE, cURus, UL | - | |
|
AM1SS-1212S-NZDC DC CONVERTER 12V 1W |
0 |
|
Технический лист |
AM1SS-NZ (1W) | 4-SIP Module | Tube | Active | Isolated Module | 1 | 10.8V | 13.2V | 12V | - | - | - | 83mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 81% | - | - | Through Hole | 0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.1mm) | - | - | cULus, cURus | - |
|
AM1SS-2409S-NZDC DC CONVERTER 9V 1W |
0 |
|
Технический лист |
AM1SS-NZ (1W) | 4-SIP Module | Tube | Active | Isolated Module | 1 | 21.6V | 26.4V | 9V | - | - | - | 110mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | - | - | Through Hole | 0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.1mm) | - | - | cULus, cURus | - |
|
AM1G-0515DZDC DC CONVERTER +/-15V 1W |
0 |
|
Технический лист |
AM1G-Z (1W) | 8-SIP Module | Tube | Active | Isolated Module | 2 | 4.5V | 9V | -15 ~ 15V | -15V | - | - | 33mA, 33mA | 1 W | 1 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 70% | - | - | Through Hole | 0.86" L x 0.36" W x 0.44" H (21.9mm x 9.2mm x 11.1mm) | - | - | CE, cURus, UL | - |
|
|
AM10CW-2415S-NZDC DC CONVERTER 15V 10W |
0 |
|
Технический лист |
AM10CW-NZ (10W) | - | Obsolete | Isolated Module | 1 | 9V | 36V | 15V | - | - | - | 660mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 87% | - | - | Through Hole | 1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm) | - | - | CE, cURus, UL | - | |
|
AM4T-1224SZDC DC CONVERTER 24V 4W |
0 |
|
Технический лист |
AM4T-Z (4W) | 24-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 18V | 24V | - | - | - | 166mA | 4 W | 3.5 kV | ITE (Commercial) | - | -40°C ~ 85°C | 80% | - | - | Through Hole | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) | - | - | CE, UL | - |
|
AM40EW-11012SH30-NZDC DC CONVERTER 12V 40W |
0 |
|
Технический лист |
AM40EW-NZ (40W) | - | Tube | Active | Isolated Module | 1 | 40V | 160V | 12V | - | - | - | 3.33A | 40 W | 3 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 89% | - | - | Through Hole | 2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 11.8mm) | - | - | CE | - |
|
AM3T-2412D-PNZDC DC CONVERTER +/-12V 3W |
0 |
|
Технический лист |
AM3T-PNZ (3W) | 24-DIP Module | Tube | Active | Isolated Module | 2 | 18V | 36V | -12 ~ 12V | -12V | - | - | 125mA, 125mA | 3 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C | 84% | - | - | Through Hole | 1.24" L x 0.80" W x 0.40" H (31.6mm x 20.3mm x 10.2mm) | - | - | - | - |
|
AM3G-2415D-NZDC DC CONVERTER +/-15V 3W |
0 |
|
Технический лист |
AM3G-NZ (3W) | 8-SIP Module | Tube | Active | Isolated Module | 2 | 18V | 36V | -15 ~ 15V | -15V | - | - | 100mA, 100mA | 3 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 100°C | 83% | - | - | Through Hole | 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm) | - | - | - | - |
|
|
AM10G-1209NZDC DC CONVERTER 9V 10W |
0 |
|
Технический лист |
AM10G-NZ (10W) | 8-SIP Module | Obsolete | Isolated Module | 1 | 9V | 18V | 9V | - | - | - | 1.11A | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 84% | - | - | Through Hole | 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm) | - | - | - | - | |
|
|
AM10CW-2424D-NZDC DC CONVERTER +/-24V 10W |
0 |
|
Технический лист |
AM10CW-NZ (10W) | - | Tube | Active | Isolated Module | 2 | 9V | 36V | -24 ~ 24V | -24V | - | - | 200mA, 200mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 87% | - | - | Through Hole | 1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm) | - | - | CE, cURus, UL | - |
|
AM2DS-0524S-NZDC DC CONVERTER 24V 2W |
0 |
|
Технический лист |
AM2DS-NZ (2W) | 7-SIP Module | Tube | Active | Isolated Module | 1 | 4.5V | 5.5V | 24V | - | - | - | 83mA | 2 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 84% | - | - | Through Hole | 0.77" L x 0.27" W x 0.39" H (19.6mm x 7.0mm x 10.0mm) | - | - | cULus, cURus | - |
|
|
AM1LS-1215SH30-NZDC DC CONVERTER 15V 1W |
0 |
|
Технический лист |
AM1LS-NZ (1W) | 8-SMD Module, 5 Leads | Tube | Active | Isolated Module | 1 | 10.8V | 13.2V | 15V | - | - | - | 67mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 100°C (With Derating) | 81% | - | - | Surface Mount | 0.50" L x 0.44" W x 0.28" H (12.7mm x 11.2mm x 7.3mm) | - | - | cULus, cURus | - |
