DC-DC преобразователи
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Количество выходов | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Эффективность | Рабочая температура | Тип крепления | Размер/измерение | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1011037CHDC2-110-3003CH |
50 |
|
Технический лист |
DC2-110 (110W) | Box | Active | Chassis | 18V | 36V | 3 | 5V | 24V | - | -24V | 10A, 2A, 2A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010630CHDC2-110-3001CH |
50 |
|
Технический лист |
DC2-110 (110W) | Box | Active | Chassis | 18V | 36V | 3 | 5V | 12V | - | -12V | 10A, 3A, 3A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
1010687CHDC4-150-1005CH |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Chassis | 36V | 72V | 1 | 15V | - | - | - | 10A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010663CHDC2-150-1003CH |
50 |
|
Технический лист |
DC2-150 (150W) | Box | Active | Chassis | 18V | 36V | 1 | 5V | - | - | - | 30A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010683CHDC4-150-1001CH |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Chassis | 36V | 72V | 1 | 2.5V | - | - | - | 30A | 75W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010684CHDC4-150-1002CH |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Chassis | 36V | 72V | 1 | 3.3V | - | - | - | 30A | 99W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010685CHDC4-150-1003CH |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Chassis | 36V | 72V | 1 | 5V | - | - | - | 30A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010690CHDC4-150-1008CH |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Chassis | 36V | 72V | 1 | 48V | - | - | - | 3.1A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010667CHDC2-150-1007CH |
50 |
|
Технический лист |
DC2-150 (150W) | Box | Active | Chassis | 18V | 36V | 1 | 28V | - | - | - | 5.4A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010666CHDC2-150-1006CH |
50 |
|
Технический лист |
DC2-150 (150W) | Box | Active | Chassis | 18V | 36V | 1 | 24V | - | - | - | 6.3A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010662CHDC2-150-1002CH |
50 |
|
Технический лист |
DC2-150 (150W) | Box | Active | Chassis | 18V | 36V | 1 | 3.3V | - | - | - | 30A | 99W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010686CHDC4-150-1004CH |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Chassis | 36V | 72V | 1 | 12V | - | - | - | 12.5A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010661CHDC2-150-1001CH |
50 |
|
Технический лист |
DC2-150 (150W) | Box | Active | Chassis | 18V | 36V | 1 | 2.5V | - | - | - | 30A | 75W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010689CHDC4-150-1007CH |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Chassis | 36V | 72V | 1 | 28V | - | - | - | 5.4A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010665CHDC2-150-1005CH |
50 |
|
Технический лист |
DC2-150 (150W) | Box | Active | Chassis | 18V | 36V | 1 | 15V | - | - | - | 10A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010832CHDC4-150-1009CH |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Chassis | 36V | 72V | 1 | 20V | - | - | - | 7.5A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010664CHDC2-150-1004CH |
50 |
|
Технический лист |
DC2-150 (150W) | Box | Active | Chassis | 18V | 36V | 1 | 12V | - | - | - | 12.5A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010688CHDC4-150-1006CH |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Chassis | 36V | 72V | 1 | 24V | - | - | - | 6.3A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
1011942CHDC2-150-1009 CH |
50 |
|
Технический лист |
DC2-150 (150W) | Tape & Box (TB) | Active | Chassis | 18V | 36V | 1 | 20V | - | - | - | 7.5A | 150W | - | Industrial, ITE (Commercial), Laboratory, Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.25" L x 3.96" W x 1.48" H (156.8mm x 100.5mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
1010654DC4-110-4001 |
93 |
|
Технический лист |
DC4-110 (110W) | Box | Active | Open Frame | 36V | 72V | 4 | 3.3V | 5V | 12V | -12V | 10A, 6A, 2A, 2A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
