DC-DC преобразователи
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Количество выходов | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Эффективность | Рабочая температура | Тип крепления | Размер/измерение | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1010625CHCODC2-110-2001CHCO |
50 |
|
Технический лист |
DC2-110 (110W) | Box | Active | Enclosed | 18V | 36V | 2 | 3.3V | 5V | - | - | 10A, 6A | 63W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010628CHCODC2-110-2004CHCO |
50 |
|
Технический лист |
DC2-110 (110W) | Box | Active | Enclosed | 18V | 36V | 2 | 12V | -12V | - | - | 5A, 4A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010650CHCODC4-110-2004CHCO |
50 |
|
Технический лист |
DC4-110 (110W) | Box | Active | Enclosed | 36V | 72V | 2 | 12V | -12V | - | - | 5A, 4A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010649CHCODC4-110-2003CHCO |
50 |
|
Технический лист |
DC4-110 (110W) | Box | Active | Enclosed | 36V | 72V | 2 | 5V | 24V | - | - | 10A, 3A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010647CHCODC4-110-2001CHCO |
50 |
|
Технический лист |
DC4-110 (110W) | Box | Active | Enclosed | 36V | 72V | 2 | 3.3V | 5V | - | - | 10A, 6A | 63W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010627CHCODC2-110-2003CHCO |
50 |
|
Технический лист |
DC2-110 (110W) | Box | Active | Enclosed | 18V | 36V | 2 | 5V | 24V | - | - | 10A, 3A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010648CHCODC4-110-2002CHCO |
50 |
|
Технический лист |
DC4-110 (110W) | Box | Active | Enclosed | 36V | 72V | 2 | 5V | 12V | - | - | 10A, 5A | 63W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010651CHCODC4-110-2005CHCO |
50 |
|
Технический лист |
DC4-110 (110W) | Box | Active | Enclosed | 36V | 72V | 2 | 15V | -15V | - | - | 4A, 3A | 105W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
1010631DC2-110-3002 |
55 |
|
Технический лист |
DC2-110 (110W) | Box | Active | Open Frame | 18V | 36V | 3 | 5V | 15V | - | -15V | 10A, 2A, 2A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010653DC4-110-3002 |
50 |
|
Технический лист |
DC4-110 (110W) | Box | Active | Open Frame | 36V | 72V | 3 | 5V | 15V | - | -15V | 10A, 2A, 2A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010630DC2-110-3001 |
37 |
|
Технический лист |
DC2-110 (110W) | Box | Active | Open Frame | 18V | 36V | 3 | 5V | 12V | - | -12V | 10A, 3A, 3A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.00" L x 3.00" W x 1.32" H (127.0mm x 76.2mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
1010686DC4-150-1004 |
99 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Open Frame | 36V | 72V | 1 | 12V | - | - | - | 12.5A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010687DC4-150-1005 |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Open Frame | 36V | 72V | 1 | 15V | - | - | - | 10A | 150W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010662DC2-150-1002 |
50 |
|
Технический лист |
DC2-150 (150W) | Box | Active | Open Frame | 18V | 36V | 1 | 3.3V | - | - | - | 30A | 99W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010661DC2-150-1001 |
50 |
|
Технический лист |
DC2-150 (150W) | Box | Active | Open Frame | 18V | 36V | 1 | 2.5V | - | - | - | 30A | 75W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010684DC4-150-1002 |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Open Frame | 36V | 72V | 1 | 3.3V | - | - | - | 30A | 99W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010683DC4-150-1001 |
50 |
|
Технический лист |
DC4-150 (150W) | Box | Active | Open Frame | 36V | 72V | 1 | 2.5V | - | - | - | 30A | 75W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 6.00" L x 3.83" W x 1.32" H (152.4mm x 97.3mm x 33.5mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
1010652CHDC4-110-3001CH |
50 |
|
Технический лист |
DC4-110 (110W) | Box | Active | Chassis | 36V | 72V | 3 | 5V | 12V | - | -12V | 10A, 3A, 3A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010653CHDC4-110-3002CH |
50 |
|
Технический лист |
DC4-110 (110W) | Box | Active | Chassis | 36V | 72V | 3 | 5V | 15V | - | -15V | 10A, 2A, 2A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
|
|
1010631CHDC2-110-3002CH |
50 |
|
Технический лист |
DC2-110 (110W) | Box | Active | Chassis | 18V | 36V | 3 | 5V | 15V | - | -15V | 10A, 2A, 2A | 110W | - | ITE (Commercial), Medical | 82% | 0°C ~ 70°C (With Derating) | Chassis Mount | 5.25" L x 3.12" W x 1.48" H (133.4mm x 79.2mm x 37.6mm) | CE, cURus, TUV, UKCA | 60601-1; 62368-1 |
