Разъемы Turret
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип клеммы | Количество башен | Длина - над платой | Длина - под фланцем | Длина - Общая | Тип крепления | Оконечная нагрузка | Диаметр фланца | Диаметр - головка башен | Внешний диаметр стороны крепления | Внешний диаметр стороны крепления | Диаметр монтажного отверстия | Толщина платы | Материал контакта | Покрытие контакта | Толщина покрытия контакта | Изоляция |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1095-0-05-15-00-00-01-0TERM TURRET PIN L=3.56MM GOLD |
0 |
|
Технический лист |
1095 | Bulk | Active | Double End, Pin | Single | 0.140" (3.56mm) | 0.949" (24.10mm) | 1.088" (27.64mm) | Through Hole | Swage, Wire Wrap | 0.115" (2.92mm) | 0.053" (1.35mm) | - | - | 0.094" (2.39mm) | 0.062" (1.57mm) | Brass Alloy | Gold | 10.0µin (0.25µm) | Non-Insulated |
|
|
2812-3-00-44-00-00-07-0TERM TURRET DOUBLE L=9.14MM |
0 |
|
Технический лист |
2812 | Bulk | Active | Double End | Double | 0.360" (9.14mm) | 0.477" (12.12mm) | 0.837" (21.26mm) | Through Hole | Swage | 0.187" (4.75mm) | 0.082" (2.08mm), 0.145" (3.68mm) | - | - | 0.116" (2.95mm) | 0.125" (3.18mm) | Brass Alloy | Silver | 300.0µin (7.62µm) | Non-Insulated |
|
|
11308TERM TURRET SINGLE L=11.1MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Double | 0.437" (11.10mm) | 0.165" (4.19mm) | 0.602" (15.29mm) | Through Hole | Press-Fit | 0.172" (4.37mm) | 0.093" (2.36mm) | - | - | 0.136" (3.45mm) | 0.062" (1.57mm) | Brass | Tin | - | Insulated |
|
|
11320TERM TURRET SINGLE L=3.81MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Single | 0.150" (3.81mm) | 0.100" (2.54mm) | 0.160" (4.06mm) | Through Hole | Press-Fit | 0.172" (4.37mm) | 0.080" (2.03mm) | - | - | 0.136" (3.45mm) | 0.062" (1.57mm) | Brass | Tin | - | Insulated |
|
|
11307TERM TURRET SINGLE L=7.37MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Double | 0.290" (7.37mm) | 0.250" (6.35mm) | 0.540" (13.72mm) | Through Hole | Press-Fit | 0.172" (4.37mm) | 0.093" (2.36mm) | - | - | 0.136" (3.45mm) | 0.062" (1.57mm) | Brass | Tin | - | Insulated |
|
|
1095-0-05-21-00-00-01-0TERM TURRET PIN L=3.56MM GOLD |
0 |
|
Технический лист |
1095 | Bulk | Active | Double End, Pin | Single | 0.140" (3.56mm) | 0.949" (24.10mm) | 1.088" (27.64mm) | Through Hole | Swage, Wire Wrap | 0.115" (2.92mm) | 0.053" (1.35mm) | - | - | 0.094" (2.39mm) | 0.062" (1.57mm) | Brass Alloy | Gold | 20.0µin (0.51µm) | Non-Insulated |
|
|
11111TERM TURRET HOLLOW L=9.91MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End, Fork, Hollow | Single | 0.390" (9.91mm) | 0.150" (3.81mm) | 0.540" (13.72mm) | Through Hole | Press-Fit | 0.187" (4.75mm) | - | - | - | 0.158" (4.01mm) | 0.062" (1.57mm) | Brass | Tin | - | Insulated |
|
|
11112TERM TURRET HOLLOW L=11.51MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End, Fork, Hollow | Single | 0.453" (11.51mm) | 0.150" (3.81mm) | 0.603" (15.32mm) | Through Hole | Press-Fit | 0.187" (4.75mm) | - | - | - | 0.158" (4.01mm) | 0.062" (1.57mm) | Brass | Tin | - | Insulated |
|
11503TERM TURRET SINGLE L=9.53MM TIN |
0 |
|
- |
- | Bulk | Obsolete | Single End | Single | 0.375" (9.53mm) | 0.218" (5.54mm) | 0.593" (15.06mm) | Panel Mount | Threaded | 0.156" (3.96mm) Hex | 0.093" (2.36mm) | - | - | - | - | Brass | Tin | - | Insulated |
|
|
11510TERM TURRET SINGLE L=9.93MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Single | 0.391" (9.93mm) | - | 0.391" (9.93mm) | Panel Mount | Threaded | 0.156" (3.96mm) Hex | 0.072" (1.83mm) | - | - | - | - | Brass | Tin | - | Insulated |
|
11500TERM TURRET SINGLE L=9.93MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Single | 0.391" (9.93mm) | 0.125" (3.18mm) | 0.516" (13.11mm) | Panel Mount | Threaded | 0.156" (3.96mm) Hex | 0.072" (1.83mm) | - | - | - | - | Brass | Tin | - | Insulated |
|
11501TERM TURRET SINGLE L=11.53MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Single | 0.454" (11.53mm) | 0.125" (3.18mm) | 0.579" (14.71mm) | Panel Mount | Threaded | 0.156" (3.96mm) Hex | 0.072" (1.83mm) | - | - | - | - | Brass | Tin | - | Insulated |
|
11502TERM TURRET SINGLE L=11.53MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Single | 0.454" (11.53mm) | 0.187" (4.75mm) | 0.641" (16.28mm) | Panel Mount | Threaded | 0.156" (3.96mm) Hex | 0.072" (1.83mm) | - | - | - | - | Brass | Tin | - | Insulated |
|
|
11511TERM TURRET SINGLE L=13.89MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Single | 0.547" (13.89mm) | - | 0.547" (13.89mm) | Panel Mount | Threaded | 0.156" (3.96mm) Hex | 0.072" (1.83mm) | - | - | - | - | Brass | Tin | - | Insulated |
|
|
11512TERM TURRET SINGLE L=15.09MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Double | 0.594" (15.09mm) | - | 0.594" (15.09mm) | Panel Mount | Threaded | 0.250" (6.35mm) Hex | 0.093" (2.36mm) | - | - | - | - | Brass | Tin | - | Insulated |
|
|
11513TERM TURRET SINGLE L=23.83MM TIN |
0 |
|
Технический лист |
- | Bulk | Active | Single End | Double | 0.938" (23.83mm) | - | 0.938" (23.83mm) | Panel Mount | Threaded | 0.250" (6.35mm) Hex | 0.140" (3.56mm) | - | - | - | - | Brass | Tin | - | Insulated |
|
|
2512-1-00-44-00-00-07-0TERM TURRET DOUBLE L=5.56MM |
0 |
|
Технический лист |
2512 | Bulk | Active | Double End | Double | 0.219" (5.56mm) | 0.250" (6.35mm) | 0.469" (11.90mm) | Through Hole | Swage | 0.125" (3.18mm) | 0.064" (1.63mm) | - | - | 0.094" (2.39mm) | 0.031" (0.79mm) | Brass Alloy | Silver | 300.0µin (7.62µm) | Non-Insulated |
|
|
2513-3-00-50-00-00-07-0TERM TURRET SINGLE L=4.78MM |
0 |
|
Технический лист |
2513 | Bulk | Active | Single End | Double | 0.188" (4.78mm) | 0.125" (3.18mm) | 0.313" (7.95mm) | Through Hole | Swage | 0.125" (3.18mm) | 0.060" (1.52mm) | 0.060" (1.52mm) | 0.041" (1.04mm) | 0.064" (1.63mm) | 0.094" (2.39mm) | Brass Alloy | Tin-Lead | 300.0µin (7.62µm) | Non-Insulated |
|
|
2561-1-00-01-00-00-07-0TERM TURRET SINGLE L=5.56MM |
0 |
|
Технический лист |
2561 | Bulk | Active | Single End | Double | 0.219" (5.56mm) | 0.063" (1.60mm) | 0.282" (7.16mm) | Through Hole | Swage | 0.125" (3.18mm) | 0.094" (2.39mm) | 0.090" (2.29mm) | 0.064" (1.63mm) | 0.094" (2.39mm) | 0.031" (0.79mm) | Brass Alloy | Tin-Lead | 200.0µin (5.08µm) | Non-Insulated |
|
|
2561-4-00-50-00-00-07-0TERM TURRET SINGLE L=5.56MM |
0 |
|
Технический лист |
2561 | Bulk | Active | Single End | Double | 0.219" (5.56mm) | 0.156" (3.96mm) | 0.375" (9.53mm) | Through Hole | Swage | 0.125" (3.18mm) | 0.094" (2.39mm) | 0.090" (2.29mm) | 0.064" (1.63mm) | 0.094" (2.39mm) | 0.125" (3.18mm) | Brass Alloy | Tin-Lead | 300.0µin (7.62µm) | Non-Insulated |
