Реле мощности, более 2 А
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип крепления | Напряжение катушки | Форма контакта | Номинал контакта (ток) | Напряжение переключения | Нагрузка - макс. переключение | Ток катушки | Тип катушки | Особенности | Тип вывода | Номинал уплотнения | Изоляция катушки | Необходимое рабочее напряжение | Необходимое отпускающее напряжение | Время срабатывания | Время отпускания | Рабочая температура | Материал контакта | Сертифицирующее агентство | Тип реле | Марка | Квалификация |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
G7J-2A2B-P DC100RELAY GEN PURPOSE 4PST 25A 100V |
0 |
|
Технический лист |
G7J | Bulk | Active | Through Hole | 100VDC | 4PST-2NO/2NC (2 Form A, 2 Form B) | 25 A | 250VAC, 125VDC - Max | 6250VA, 3125W | 20 mA | Non Latching | Test Button | PC Pin | - | - | 75 VDC | 10 VDC | 50 ms | 50 ms | -25°C ~ 60°C | - | CE, CSA, UR | General Purpose | - | - |
|
|
G7J-4A-P AC50RELAY GEN PURPOSE 4PST 25A 50V |
0 |
|
Технический лист |
G7J | Bulk | Active | Through Hole | 50VAC | 4PST-NO (DM) (4 Form X) | 25 A | 250VAC, 125VDC - Max | 6250VA, 3125W | 36 mA | Non Latching | Test Button | PC Pin | - | - | 37.5 VAC | 7.5 VAC | 50 ms | 50 ms | -25°C ~ 60°C | - | CE, CSA, UR | General Purpose | - | - |
|
|
G7J-4A-PZ DC24RELAY GEN PURPOSE 4PST 25A 24V |
0 |
|
Технический лист |
G7J | Bulk | Active | Through Hole | 24VDC | 4PST-NO (DM) (4 Form X) | 25 A | 250VAC, 125VDC - Max | 6250VA, 3125W | 83 mA | Non Latching | Test Button | PC Pin | - | - | 18 VDC | 2.4 VDC | 50 ms | 50 ms | -25°C ~ 60°C | - | CE, CSA, UR | General Purpose | - | - |
|
|
G7J-4A-P DC100RELAY GEN PURPOSE 4PST 25A 100V |
0 |
|
Технический лист |
G7J | Bulk | Active | Through Hole | 100VDC | 4PST-NO (DM) (4 Form X) | 25 A | 250VAC, 125VDC - Max | 6250VA, 3125W | 20 mA | Non Latching | Test Button | PC Pin | - | - | 75 VDC | 10 VDC | 50 ms | 50 ms | -25°C ~ 60°C | - | CE, CSA, UR | General Purpose | - | - |
|
|
CF30A20024RELAY GEN PURPOSE DPST 30A 24V |
0 |
|
Технический лист |
CF30 | Box | Not For New Designs | Chassis Mount | 24VAC | DPST-NO (2 Form A) | 30 A | 277VAC, 30VDC - Max | 8310VA, 900W | 615.4 mA | Non Latching | - | Quick Connect - 0.250" (6.3mm) | Sealed - Fully | Class F | 19.2 VAC | 4.8 VAC | 15 ms | 10 ms | -40°C ~ 65°C | Silver Tin Oxide (AgSnO) | CE, cURus | General Purpose | - | - |
|
R10-E2Y2-S3.2KRELAY GEN PURPOSE DPDT 3A 24V |
0 |
|
Технический лист |
R10 | Bulk | Active | Through Hole | 24VDC | DPDT (2 Form C) | 3 A | 120VAC - Nom | - | 7.5 mA | Non Latching | - | PC Pin | - | - | 18 VDC | - | - | - | -55°C ~ 75°C | Silver (Ag) | CSA, UR | General Purpose | - | - |
|
1102121001RELAY GEN PURPOSE SPST 5A 115V |
1 |
|
Технический лист |
RS | Bulk | Obsolete | DIN Rail | 115VAC | SPST-NO (1 Form A) | 5 A | 250VAC - Max | 1250VA | - | Non Latching | Lighted Indicator, Socket Included | Screw Terminal | - | - | - | - | 9 ms | 8 ms | -25°C ~ 40°C | Silver Nickel (AgNi) | CE | General Purpose | - | - |
|
859-391RELAY GEN PURPOSE SPDT 5A 110V |
0 |
|
Технический лист |
859 | Box | Active | DIN Rail | 110VDC | SPDT (1 Form C) | 5 A | 250VAC - Max | 1250VA | 2.7 mA | Non Latching | Lighted Indicator | Spring Terminal | - | - | - | - | 15 ms | 25 ms | -40° ~ 70°C | Silver Tin Oxide (AgSnO) | - | General Purpose | - | - |
|
|
PRD-60984POWER RELAY ASSEMBLY |
0 |
|
- |
PRD | Bulk | Obsolete | Chassis Mount | - | - | 50 A | 600VAC, 125VDC - Nom | - | - | Non Latching | - | - | - | Class B | - | - | 40 ms | 20 ms | - | - | CSA, UL | General Purpose | - | - |
|
|
LZX:PT580730PLUG-IN RELAY |
0 |
|
- |
SIRIUS LZX | Box | Active | Socketable | 230VAC | 4PDT (4 Form C) | 4 A | 24VDC - Max | 96W | - | Non Latching | - | Plug In | - | - | 207 VAC | - | - | - | -40°C ~ 70°C | Silver Nickel (AgNi), Gold (Au) | CE, EAC, UKCA, UR, VDE | General Purpose | - | - |
|
|
199X2OPEN PWR RY, SPDT, 40A, 12VDC |
0 |
|
Технический лист |
SE | Box | Obsolete | Chassis Mount | 12VDC | SPDT (1 Form C) | 40 A | 600VDC - Max | 24000W | 171.4 mA | Non Latching | - | Screw Terminal | - | - | 10.2 VDC | 1.2 VDC | - | - | -55°C ~ 55°C | Silver Alloy | CE, CSA, cULus | General Purpose | - | - |
|
G7J-3A1B-B-W1 AC200/240RELAY GEN PURPOSE 4PST 25A 240V |
0 |
|
Технический лист |
G7J | Bulk | Obsolete | Chassis Mount | 240VAC | 4PST-3NO/1NC (3 Form A, 1 Form B) | 25 A | 250VAC, 125VDC - Max | 6250VA, 3125W | 10.8 mA | Non Latching | Bracket Included, Test Button | Screw Terminal | - | - | 150 VAC | 36 VAC | 50 ms | 50 ms | -25°C ~ 60°C | - | CE, CSA, UR | General Purpose | - | - |
|
|
MGN1A-AC240RELAY GEN PURPOSE SPST 30A 240V |
0 |
|
Технический лист |
MGN | Bulk | Active | Chassis Mount | 240VAC | SPST-NO (1 Form A) | 30 A | 600VAC, 28VDC - Max | 18000VA, 840W | 40 mA | Non Latching | - | Screw Terminal | - | Class F | 204 VAC | - | 30 ms | 30 ms | -45°C ~ 80°C | - | cURus | General Purpose | - | - |
|
|
MGN1A-DC12RELAY GEN PURPOSE SPST 30A 12V |
0 |
|
Технический лист |
MGN | Bulk | Active | Chassis Mount | 12VDC | SPST-NO (1 Form A) | 30 A | 600VAC, 28VDC - Max | 18000VA, 840W | 167 mA | Non Latching | - | Screw Terminal | - | Class F | 9 VDC | - | 30 ms | 30 ms | -40°C ~ 115°C | - | cURus | General Purpose | - | - |
|
|
MGN1A-DC24RELAY GEN PURPOSE SPST 30A 24V |
0 |
|
Технический лист |
MGN | Bulk | Active | Chassis Mount | 24VDC | SPST-NO (1 Form A) | 30 A | 600VAC, 28VDC - Max | 18000VA, 840W | 83.3 mA | Non Latching | - | Screw Terminal | - | Class F | 18 VDC | - | 30 ms | 30 ms | -40°C ~ 115°C | - | cURus | General Purpose | - | - |
|
|
MGN1A-DC48RELAY GEN PURPOSE SPST 30A 48V |
0 |
|
Технический лист |
MGN | Bulk | Active | Chassis Mount | 48VDC | SPST-NO (1 Form A) | 30 A | 600VAC, 28VDC - Max | 18000VA, 840W | 41.6 mA | Non Latching | - | Screw Terminal | - | Class F | 36 VDC | - | 30 ms | 30 ms | -40°C ~ 115°C | - | cURus | General Purpose | - | - |
|
|
MK3ZP-2-DC24RELAY GEN PURPOSE 3PDT 10A 24V |
0 |
|
- |
MK | Bulk | Active | Socketable | 24VDC | 3PDT (3 Form C) | 10 A | 250VAC, 250VDC - Max | 2500VA, 280W | 56 mA | Non Latching | - | Plug In, 11 Pin (Octal) | - | - | 19.2 VDC | 3.6 VDC | 30 ms | 20 ms | -10°C ~ 40°C | Silver (Ag) | DEMKO, SEV, TUV, UL | General Purpose | - | - |
|
R10-E1Y4-J2.5KRELAY GEN PURPOSE 4PDT 3A 24V |
0 |
|
Технический лист |
R10 | Bulk | Active | Socketable | 24VDC | 4PDT (4 Form C) | 3 A | 120VAC - Nom | - | 28 mA | Non Latching | - | Plug In | - | - | 21 VDC | - | - | - | -55°C ~ 75°C | Silver (Ag) | CSA, UR | General Purpose | - | - |
|
8501RSD42V53PLUG IN RELAY, TYPE R, MINIATURE |
0 |
|
Технический лист |
Square D 8501R | Box | Active | Socketable | 24VDC | DPDT (2 Form C) | 15 A | 300VAC, 30VDC - Max | 4500VA, 450W | - | Non Latching | - | Plug In | - | - | - | - | 20 ms | 20 ms | -40°C ~ 55°C | Silver (Ag), Gold (Au) | - | General Purpose | - | - |
|
8501RSD42V51PLUG IN RELAY, TYPE R, MINIATURE |
0 |
|
Технический лист |
Square D 8501R | Box | Active | Socketable | 12VDC | DPDT (2 Form C) | 15 A | 300VAC, 30VDC - Max | 4500VA, 450W | - | Non Latching | - | Plug In | - | - | - | - | 20 ms | 20 ms | -40°C ~ 55°C | Silver (Ag), Gold (Au) | - | General Purpose | - | - |
