Светодиодные COB, двигатели, модули, полосы
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип | Цвет | CCT (K) | Длина волны | Конфигурация | Световой поток при токе/температуре | Ток - Тест | Температура - Тест | Напряжение - прямое (Vf) (тип.) | Люмен/Ватт при токе - Тест | Ток - макс. | CRI (индекс цветопередачи) | Угол обзора | Особенности | Размер/измерение | Высота | Светоизлучающая поверхность (LES) | Тип линзы |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SI-B8V15156CWWLED MOD LT-V562B LNR STRP 3000K |
437 |
|
Технический лист |
LT-V562B | Tray | Obsolete | LED Module | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Linear Light Strip | 2045lm (Typ) | 630mA | 50°C | 25.4V | 128 lm/W | 720mA | 80 | 120° | With Connector | 560.00mm L x 18.00mm W | 5.50mm | - | Flat |
|
SPHWHSHDNE27YZV3D4LED COB D GEN4 WHT SQUARE 3000K |
240 |
|
Технический лист |
COB D Gen4 | Tape & Reel (TR) | Obsolete | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 2509lm (Typ) | 450mA | 85°C | 33.6V | 166 lm/W | 1.15A | 90 | 115° | - | 19.00mm L x 19.00mm W | 1.70mm | 14.50mm Dia | Flat |
|
|
SI-B8T15156CWWLED MOD LT-V562B LNR STRP 4000K |
229 |
|
Технический лист |
LT-V562B | Tray | Obsolete | LED Module | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Linear Light Strip | 2157lm (Typ) | 630mA | 50°C | 25.4V | 135 lm/W | 720mA | 80 | 120° | With Connector | 560.00mm L x 18.00mm W | 5.50mm | - | Flat |
|
|
CXM-9-24-90-36-TC60-F7-2LED COB CXM-9 WARM WHT SQ 2400K |
788 |
|
Технический лист |
CXM-9 Gen 6 | Tray | Active | Chip On Board (COB) | White, Warm | 2400K 2-Step MacAdam Ellipse | - | Square | 1525lm (Typ) | 360mA | 85°C | 33.2V | 128 lm/W | 1A | 90 | 120° | - | 13.50mm L x 13.50mm W | 1.40mm | 9.60mm Dia | Flat |
|
|
SI-B8R031500WWLED MOD SE WHT LNR STRP 5000K |
566 |
|
Технический лист |
Standard Back-lit S.E | Bulk | Active | LED Module | White, Cool | 5000K | - | Linear Light Strip | 650lm (Typ) | 88mA | 40°C | 41.5V | 178 lm/W | 200mA | 80 | 160° | - | 500.00mm L x 13.00mm W | 6.00mm | - | Flat |
|
|
SI-B8V031500WWLED MOD SE WHT LNR STRP 3000K |
529 |
|
Технический лист |
Standard Back-lit S.E | Bulk | Active | LED Module | White, Warm | 3000K | - | Linear Light Strip | 610lm (Typ) | 88mA | 40°C | 41.5V | 167 lm/W | 200mA | 80 | 160° | - | 500.00mm L x 13.00mm W | 6.00mm | - | Flat |
|
SI-B8U072280WWLED MOD LTM282BG2 WARM WHT STRIP |
191 |
|
Технический лист |
LT-M282B_G2 | Tray | Obsolete | LED Module | White, Warm | 3500K 4-Step MacAdam Ellipse | - | Linear Light Strip | 1070lm (Typ) | 300mA | 50°C | 24.8V | 144 lm/W | 360mA | 80 | 115° | With Connector | 275.00mm L x 18.00mm W | 4.40mm | - | Flat |
|
SDW01F1C-D/E-CALED COB ZC6 CL WH SQUARE 5000K |
255 |
|
- |
ZC6 Z-Power COB | Tray | Obsolete | Chip On Board (COB) | White, Cool | 5000K | - | Square | 870lm (Typ) | 180mA | 25°C | 37V | 131 lm/W | 320mA | 70 | 120° | - | 13.50mm L x 13.50mm W | 2.30mm | - | Flat |
|
|
SI-B8R041500WWLED MOD COOL WHT LNR STRIP 5000K |
280 |
|
Технический лист |
- | Bulk | Last Time Buy | LED Module | White, Cool | 5000K | - | Linear Light Strip | 830lm (Typ) | 110mA | 40°C | 40.8V | 185 lm/W | 300mA | 80 | 160° | - | 500.00mm L x 13.00mm W | 7.00mm | - | Flat |
|
|
SPHWHAHDNH23YZT3DBLED COB D GEN2 NEUT WHT SQ 4000K |
250 |
|
Технический лист |
COB D Gen2 Plus | Box | Last Time Buy | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 5175lm (Typ) | 900mA | 85°C | 34V | 169 lm/W | 1.8A | 70 | 115° | - | 19.00mm L x 19.00mm W | 1.50mm | 14.50mm Dia | Flat |
|
|
SPHWHAHDNH25YZV3DBLED COB D GEN2 WM WHT SQ 3000K |
215 |
|
Технический лист |
COB D Gen2 Plus | Box | Active | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 5014lm (Typ) | 900mA | 85°C | 34V | 164 lm/W | 1.8A | 80 | 115° | - | 19.00mm L x 19.00mm W | 1.50mm | 14.50mm Dia | Flat |
|
|
SPHWHAHDNH27YZR3DBLED COB D GEN2 COOL WHT SQ 5000K |
114 |
|
Технический лист |
COB D Gen2 Plus | Box | Last Time Buy | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 5202lm (Typ) | 900mA | 85°C | 34V | 170 lm/W | 1.8A | 90 | 115° | - | 19.00mm L x 19.00mm W | 1.50mm | 14.50mm Dia | Flat |
|
|
CMU1516-0000-00PN0U0A30HXLAMP CMU LED WHITE PRO9 |
223 |
|
Технический лист |
XLamp® CMU1516 | Tray | Active | Chip On Board (COB) | White, Warm | 3000K 2-Step MacAdam Ellipse | - | Square | 2575lm (Typ) | 450mA | 85°C | 33.7V | 170 lm/W | 1.2A | 90 | 115° | - | 19.00mm L x 19.00mm W | 1.50mm | 14.50mm Dia | Flat |
|
SI-B8R114280WWLED MOD LTM282CG2 COOL WHT STRIP |
1,937 |
|
Технический лист |
LT-M282C_G2 | Tray | Obsolete | LED Module | White, Cool | 5000K 4-Step MacAdam Ellipse | - | Linear Light Strip | 1650lm (Typ) | 450mA | 50°C | 24.8V | 148 lm/W | 540mA | 80 | 115° | With Connector | 275.00mm L x 18.00mm W | 4.40mm | - | Flat |
|
|
SPHWHSHDNG27YZW3D4LED COB D GEN4 WHT SQUARE 2700K |
250 |
|
Технический лист |
COB D Gen4 | Tray | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 3896lm (Typ) | 720mA | 85°C | 33.6V | 161 lm/W | 1.84A | 90 | 115° | - | 19.00mm L x 19.00mm W | 1.70mm | 14.50mm Dia | Flat |
|
|
SPHWHSHDNG27YZT3D4LED COB D GEN4 WHT SQUARE 4000K |
249 |
|
Технический лист |
COB D Gen4 | Tape & Reel (TR) | Obsolete | Chip On Board (COB) | White, Neutral | 4000K 3-Step MacAdam Ellipse | - | Square | 4134lm (Typ) | 720mA | 85°C | 33.6V | 171 lm/W | 1.84A | 90 | 115° | - | 19.00mm L x 19.00mm W | 1.70mm | 14.50mm Dia | Flat |
|
|
SPHWHSHDNG27YZR3D4LED COB D GEN4 WHT SQUARE 5000K |
244 |
|
Технический лист |
COB D Gen4 | Tray | Obsolete | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 4141lm (Typ) | 720mA | 85°C | 33.6V | 171 lm/W | 1.84A | 90 | 115° | - | 19.00mm L x 19.00mm W | 1.70mm | 14.50mm Dia | Flat |
|
|
SPHWHAHDNH23YZR3DCLED COB D GEN3 COOL WHT SQ 5000K |
247 |
|
Технический лист |
COB D Gen3 Plus | Box | Active | Chip On Board (COB) | White, Cool | 5000K 3-Step MacAdam Ellipse | - | Square | 5424lm (Typ) | 900mA | 85°C | 33.7V | 179 lm/W | 1.8A | 70 | 115° | - | 19.00mm L x 19.00mm W | 1.50mm | 14.50mm Dia | Flat |
|
|
SI-B8R11428001LED MOD LTM282C LNR STRP 5000K |
194 |
|
Технический лист |
LT-M282C Gen3 | Tray | Active | LED Module | White, Cool | 5000K | - | Linear Light Strip | 1650lm | 450mA | - | 24.8V | 148 lm/W | 540mA | 80 | 115° | - | 275.00mm L x 18.00mm W | 5.80mm | - | Flat |
|
|
SI-B8T123560WWLED MOD V GEN3 WH LNR STR 4000K |
235 |
|
- |
V Gen3 | Tray | Active | LED Module | White, Neutral | 4000K | - | Linear Light Strip | 2200lm (Typ) | 530mA | 50°C | 22.2V | 186 lm/W | 1.8A | 80 | 118° | - | 560.00mm L x 18.00mm W | 3.70mm | - | Flat |
