Бесщеточные вентиляторы постоянного тока (BLDC)
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Напряжение - Номинальное | Размер/измерение | Ширина | Поток воздуха | Статическое давление | Тип подшипника | Тип вентилятора | Особенности | Шум | Мощность (Вт) | Об/мин | Оконечная нагрузка | Защита от проникновения | Рабочая температура | Сертифицирующее агентство | Вес |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
9RA1448M10011140X38MM 48VDC LOW NOISE RBLS TA |
14 |
|
Технический лист |
San Ace 140 | Box | Active | 48VDC | Square - 140mm L x 140mm H | 38.00mm | 113.0 CFM (3.16m³/min) | 0.220 in H2O (54.8 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 36.0dB(A) | 2.9 W | 2250 RPM | 3 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | cURus, TUV | - |
|
8218JH3FAN AXIAL 80X38MM 48VDC WIRE |
0 |
|
Технический лист |
8200J, S-Force | Bulk | Active | 48VDC | Square - 80mm L x 80mm H | 38.00mm | 112.0 CFM (3.14m³/min) | - | Ball | Tubeaxial | Locked Rotor Protection | 66.0dB(A) | 25 W | 12000 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | - | - |
|
|
9RA1448P1G0011FAN AXIAL 140X140MM BALL 48VDC |
14 |
|
Технический лист |
San Ace 140 | Box | Active | 48VDC | Square - 140mm L x 140mm H | 38.00mm | 212.0 CFM (5.94m³/min) | 0.640 in H2O (159.4 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 52.0dB(A) | 13.4 W | 4250 RPM | 4 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | cURus, TUV | - |
|
|
8212J/2H3FAN AXIAL 80X38MM 12VDC WIRE |
0 |
|
- |
8200J, S-Force | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 38.00mm | 111.8 CFM (3.13m³/min) | - | Ball | Tubeaxial | Speed Sensor (Tach) | 66.0dB(A) | 26 W | 12000 RPM | 3 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | - | - |
|
|
9RA1448P1G001140X38MM 48VDC LOW NOISE TACH PW |
12 |
|
Технический лист |
San Ace 140 | Box | Active | 48VDC | Square - 140mm L x 140mm H | 38.00mm | 212.0 CFM (5.94m³/min) | 0.640 in H2O (159.4 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 52.0dB(A) | 13.4 W | 4250 RPM | 4 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | cURus, TUV | - |
|
|
17001202AFAN AXIAL 24VDC JQD24B3-E3 |
5 |
|
Технический лист |
Major | Box | Active | 24VDC | Rectangular/Rounded - 171.4mm L x 150.4mm H | 50.80mm | 235.0 CFM (6.58m³/min) | - | Ball | Tubeaxial | Auto Restart, Locked Rotor Protection | 54.3dB(A) | 24 W | 3400 RPM | 2 Wire Leads | IP68 - Dust Tight, Waterproof | 14 ~ 158°F (-10 ~ 70°C) | CE, cUL, UL | - |
|
|
17001196AFAN AXIAL 48VDC PQD48Z3E2X-E3 |
14 |
|
Технический лист |
Patriot | Bulk | Active | 48VDC | Round - 171.4mm Dia | 50.80mm | 305.0 CFM (8.54m³/min) | - | Ball | Tubeaxial | Auto Restart, Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 60.4dB(A) | 32.2 W | 4500 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | 14 ~ 158°F (-10 ~ 70°C) | CE, cUL, UL | - |
|
|
17000298AFAN AXL 254X88.9MM CD24B7 24VDC |
19 |
|
Технический лист |
- | Box | Active | 24VDC | Round - 254mm Dia | 88.90mm | 550.0 CFM (15.40m³/min) | - | Ball | Tubeaxial | Auto Restart, Locked Rotor Protection, Speed Sensor (Tach) | 49.1dB(A) | 29 W | 1650 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cUR, UL | - |
|
OD172SAP-48HTBFAN AXIAL 172X51MM 48VDC TERM |
10 |
|
Технический лист |
OD172SAP | Bulk | Active | 48VDC | Rectangular/Rounded - 172mm L x 150mm H | 51.00mm | 235.0 CFM (6.58m³/min) | 0.770 in H2O (191.8 Pa) | Ball | Tubeaxial | Auto Restart | 52.0dB(A) | 24 W | 3200 RPM | 2 Terminals | - | -13 ~ 149°F (-25 ~ 65°C) | CE, cURus, TUV, UR | - |
|
|
9LG1212F1002120X38MM 12V, HIGH PERF LONG LIF |
21 |
|
Технический лист |
San Ace 120 | Box | Active | 12VDC | Square - 120mm L x 120mm H | 38.00mm | - | - | Ball | Tubeaxial | Locked Rotor Protection | 39.0dB(A) | - | 2800 RPM | 2 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | - | - |
|
|
9LG1212M1001120X38MM 12V, HIGH PERF LONG LIF |
20 |
|
Технический лист |
San Ace 120L | Box | Active | 12VDC | Square - 120mm L x 120mm H | 38.00mm | 77.7 CFM (2.18m³/min) | 0.150 in H2O (37.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 33.0dB(A) | 2.64 W | 2100 RPM | 3 Wire Leads | - | -4 ~ 158°F (-20 ~ 70°C) | cURus, TUV | - |
|
OD172SAP-48HHTB01AFAN AXIAL 172X51MM 48VDC TERM |
22 |
|
Технический лист |
OD172SAP | Bulk | Active | 48VDC | Rectangular/Rounded - 172mm L x 150mm H | 51.00mm | 300.0 CFM (8.40m³/min) | 0.950 in H2O (237.0 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 56.0dB(A) | 49.4 W | 3850 RPM | 3 Terminals | - | -13 ~ 149°F (-25 ~ 65°C) | CE, cURus, TUV, UR | - |
|
OD1225-24LBFAN AXIAL 120X25MM 24VDC WIRE |
0 |
|
Технический лист |
OD1225 | Box | Active | 24VDC | Square - 120mm L x 120mm H | 25.00mm | 70.0 CFM (1.96m³/min) | 0.150 in H2O (37.3 Pa) | Ball | Tubeaxial | Auto Restart | 25.0dB(A) | 2.4 W | 1900 RPM | 2 Wire Leads | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | 0.341 lb (154.67 g) |
|
W2G115-AG71-09FAN AXIAL 127X38MM 24VDC TERM |
0 |
|
Технический лист |
W2G115 | Bulk | Obsolete | 24VDC | Square - 127mm L x 127mm H | 38.00mm | 160.0 CFM (4.48m³/min) | - | Ball | Tubeaxial | - | 52.0dB(A) | 12 W | - | 2 Terminals | - | - | - | 1.6 lbs (725.7 g) |
|
|
6448-384FAN AXIAL 171.5X50.8MM 48VDC |
0 |
|
- |
6400 | Bulk | Obsolete | 48VDC | Rectangular/Rounded - 171.5mm L x 150mm H | 50.80mm | 241.0 CFM (6.75m³/min) | - | Ball | Tubeaxial | - | 57.0dB(A) | 17 W | 3400 RPM | - | - | -4 ~ 162°F (-20 ~ 72°C) | - | - |
|
MM1865H48B-FSRFAN AXIAL 180X65MM 48VDC WIRE |
4 |
|
Технический лист |
MM1865 | Bulk | Obsolete | 48VDC | Square - 180mm L x 180mm H | 65.00mm | 580.0 CFM (16.24m³/min) | 1.200 in H2O (298.9 Pa) | Ball | Tubeaxial | - | 65.0dB | - | 4000 RPM | 2 Wire Leads | - | -40 ~ 158°F (-40 ~ 70°C) | cUL, TUV, UL | 3.5 lbs (1.6 kg) |
|
|
109P1348H101FAN AXIAL 127X38MM 48VDC WIRE |
17 |
|
Технический лист |
San Ace 127 | Box | Active | 48VDC | Square - 127mm L x 127mm H | 38.00mm | 134.0 CFM (3.75m³/min) | 0.394 in H2O (98.1 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 45.0dB(A) | 9.6 W | 2950 RPM | 3 Wire Leads | - | -4 ~ 140°F (-20 ~ 60°C) | CSA, TUV, UL | 0.772 lb (350.17 g) |
|
OD254AP-48LTBFAN AXIAL 254X89MM 48VDC TERM |
14 |
|
Технический лист |
OD254AP | Bulk | Active | 48VDC | Round - 254mm Dia | 89.00mm | 550.0 CFM (15.40m³/min) | 0.370 in H2O (92.2 Pa) | Ball | Tubeaxial | Auto Restart | 39.4dB(A) | 24 W | 1650 RPM | 2 Terminals | - | -4 ~ 149°F (-20 ~ 65°C) | CE, cURus, TUV, UR | - |
|
RER175-42/18/2TDMLPFAN IMP MTRZD 175X69MM 48VDC |
0 |
|
Технический лист |
RER175TD | Bulk | Active | 48VDC | Round - 175mm Dia | 69.00mm | 353.0 CFM (9.88m³/min) | - | Ball | Motorized Impellers | PWM Control, Speed Sensor (Tach) | - | 42 W | 3400 RPM | 4 Wire Leads | - | - | - | 1.7 lbs (771.1 g) |
|
MSI2577H48B1-BBRFAN IMP MTRZD 250X77.3MM 48VDC |
5 |
|
Технический лист |
MSI2577 | Box | Active | 48VDC | Round - 250mm Dia | 77.30mm | 716.0 CFM (20.05m³/min) | 3.365 in H2O (838.2 Pa) | Ball | Motorized Impellers | Auto Restart, Speed Sensor (Tach) | 76.0dB(A) | - | 2800 RPM | 3 Wire Leads | - | - | CE, cUL, TUV, UL | 4.4 lbs (2 kg) |
