DC-DC преобразователи
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Количество выходов | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Эффективность | Рабочая температура | Тип крепления | Размер/измерение | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CPP20F48DC/DC CONVERTER 3.3V 66W |
1 |
|
Технический лист |
CPP (100W) | Tray | Active | Enclosed | 36V | 75V | 1 | 3.3V | - | - | - | 20A | 66W | 2.25 kV | ITE (Commercial) | 91% | -40°C ~ 85°C | Chassis Mount | 2.00" L x 2.00" W x 1.20" H (50.8mm x 50.8mm x 30.5mm) | - | - |
|
|
CPP15F36NMDC/DC CONVERTER 3.3V 50W |
1 |
|
Технический лист |
CPP (72W) | Tray | Active | Enclosed | 18V | 72V | 1 | 3.3V | - | - | - | 15A | 50W | 2.25 kV | ITE (Commercial) | 90% | -40°C ~ 85°C | Chassis Mount | 2.00" L x 2.00" W x 1.20" H (50.8mm x 50.8mm x 30.5mm) | - | - |
|
|
CPP3C36PMDC/DC CONVERTER 15V 45W |
1 |
|
Технический лист |
CPP (72W) | Tray | Active | Enclosed | 18V | 72V | 1 | 15V | - | - | - | 3A | 45W | 2.25 kV | ITE (Commercial) | 91% | -40°C ~ 85°C | Chassis Mount | 2.00" L x 2.00" W x 1.20" H (50.8mm x 50.8mm x 30.5mm) | - | - |
|
|
CPP15A24DC/DC CONVERTER 5V 75W |
1 |
|
Технический лист |
CPP (100W) | Tray | Active | Enclosed | 18V | 36V | 1 | 5V | - | - | - | 15A | 75W | 2.25 kV | ITE (Commercial) | 92% | -40°C ~ 85°C | Chassis Mount | 2.00" L x 2.00" W x 1.20" H (50.8mm x 50.8mm x 30.5mm) | - | - |
|
|
CPP20F48PMDC/DC CONVERTER 3.3V 66W |
1 |
|
Технический лист |
CPP (100W) | Tray | Active | Enclosed | 36V | 75V | 1 | 3.3V | - | - | - | 20A | 66W | 2.25 kV | ITE (Commercial) | 91% | -40°C ~ 85°C | Chassis Mount | 2.00" L x 2.00" W x 1.20" H (50.8mm x 50.8mm x 30.5mm) | - | - |
|
76000696DC/DC CONVERTER 12V 12W |
0 |
|
Технический лист |
- | Box | Active | Enclosed | -36V | -72V | 1 | 12V | - | - | - | 1A | 12W | 1.5 kV | ITE (Commercial) | 70% | 0°C ~ 40°C | - | 2.91" L x 1.93" W x 1.59" H (74.0mm x 49.0mm x 40.5mm) | cUL, UL | - |
|
STMGFS154812DC/DC CONVERTER 12V 16W |
1 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 18V | 76V | 1 | 12V | - | - | - | 1.3A | 16W | 1.5 kV | ITE (Commercial) | 88% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS152405-JDC/DC CONVERTER 5V 15W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 9V | 36V | 1 | 5V | - | - | - | 3A | 15W | 1.5 kV | ITE (Commercial) | 88% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS152405-RDC/DC CONVERTER 5V 15W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 9V | 36V | 1 | 5V | - | - | - | 3A | 15W | 1.5 kV | ITE (Commercial) | 88% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS152412-JDC/DC CONVERTER 12V 16W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 9V | 36V | 1 | 12V | - | - | - | 1.3A | 16W | 1.5 kV | ITE (Commercial) | 89% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS152412-RDC/DC CONVERTER 12V 16W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 9V | 36V | 1 | 12V | - | - | - | 1.3A | 16W | 1.5 kV | ITE (Commercial) | 89% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS152415-JDC/DC CONVERTER 15V 15W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 9V | 36V | 1 | 15V | - | - | - | 1A | 15W | 1.5 kV | ITE (Commercial) | 89% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS152415-RDC/DC CONVERTER 15V 15W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 9V | 36V | 1 | 15V | - | - | - | 1A | 15W | 1.5 kV | ITE (Commercial) | 89% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS15243R3-JDC/DC CONVERTER 3.3V 13W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 9V | 36V | 1 | 3.3V | - | - | - | 4A | 13W | 1.5 kV | ITE (Commercial) | 87% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS15243R3-RDC/DC CONVERTER 3.3V 13W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 9V | 36V | 1 | 3.3V | - | - | - | 4A | 13W | 1.5 kV | ITE (Commercial) | 87% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS154805-JDC/DC CONVERTER 5V 15W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 18V | 76V | 1 | 5V | - | - | - | 3A | 15W | 1.5 kV | ITE (Commercial) | 88% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS154805-RDC/DC CONVERTER 5V 15W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 18V | 76V | 1 | 5V | - | - | - | 3A | 15W | 1.5 kV | ITE (Commercial) | 88% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS154812-JDC/DC CONVERTER 12V 16W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 18V | 76V | 1 | 12V | - | - | - | 1.3A | 16W | 1.5 kV | ITE (Commercial) | 88% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS154812-RDC/DC CONVERTER 12V 16W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 18V | 76V | 1 | 12V | - | - | - | 1.3A | 16W | 1.5 kV | ITE (Commercial) | 88% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
|
|
STMGFS154815DC/DC CONVERTER 15V 15W |
0 |
|
Технический лист |
STMGFS (15W) | Box | Active | Open Frame | 18V | 76V | 1 | 15V | - | - | - | 1A | 15W | 1.5 kV | ITE (Commercial) | 89% | -20°C ~ 70°C (With Derating) | Chassis Mount | 3.66" L x 2.05" W x 1.06" H (93.0mm x 52.1mm x 26.9mm) | CE | - |
