Узлы коаксиальных разъемов (РЧ)
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Тип разъема | Тип разъема | Контактное окончание | Концевая заделка экрана | Импеданс | Тип крепления | Функция монтажа | Группа кабелей | Тип крепления | Частота - Макс. | Количество портов | Особенности | Цвет корпуса | Защита от проникновения | Материал центрального контакта |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CBBJ159CONN TRS JACK STR PCB |
105 |
|
Технический лист |
150 | Bulk | Active | TRS, Twinaxial/Triaxial | Jack, Female Socket | Solder | Solder | - | Panel Mount, Through Hole | Bulkhead - Front Side Nut | - | Bayonet Lock | 500 MHz | 1 | Three Lug | Silver | - | - |
|
SF1621-60036CONN 2.4MM JACK STR 50OHM EDGEMT |
33 |
|
Технический лист |
2.4mm | Bulk | Active | 2.4mm (APC-2.4, OS-50) | Jack, Female Socket | Compression | Screw | 50 Ohms | Board Edge, End Launch | - | - | Threaded | 50 GHz | - | Mounting Hardware | Silver | - | Beryllium Copper |
|
SF3321-600331.85MM FEMALE SOLDERLESS LITETOU |
39 |
|
Технический лист |
1.85mm | Tray | Active | 1.85mm | Jack, Female Socket | Compression | Screw | 50 Ohms | Surface Mount | Flange | - | Threaded | 65 GHz | 1 | - | Silver | - | Beryllium Copper |
|
D-621-0011CONN TRIAX PLUG STR SOLDER |
87 |
|
Технический лист |
D-621 | Bulk | Active | Triaxial | Plug, Male Pin | Solder | Solder | - | Free Hanging (In-Line) | - | - | Threaded | - | 1 | - | Silver | - | - |
|
CBBJR39ACONN TWINAX JACK R/A PCB |
327 |
|
Технический лист |
30 | Bulk | Active | BNC, Twinaxial | Jack, Female Socket, Male Pin (Concentric) | Solder | Solder | - | Panel Mount, Through Hole, Right Angle | Bulkhead - Front Side Nut | - | Bayonet Lock | 500 MHz | 1 | Board Guide | Silver | - | - |
|
3811-60050SMPS MALE EDGE LAUNCH CONNECTOR, |
42 |
|
Технический лист |
SMPS | Bulk | Active | SMPS | Plug, Male Pin | Solder | Solder | 50 Ohms | Board Edge, Cutout; Surface Mount | - | - | Snap-On | 65 GHz | 2 | Smooth Bore | Gold | - | Beryllium Copper |
|
000-28175CONN MHV JACK STR SOLDER |
63 |
|
Технический лист |
- | Bulk | Active | MHV | Jack, Female Socket | Solder | Clamp | Non-Constant | Panel Mount | Flange | RG-59, 59B, 62, 140, 210, Belden 8241, 8263, 8279, 9209 | Bayonet Lock | 50 GHz | 1 | - | Silver | Weatherproof | Beryllium Copper |
|
|
24_SHV-50-3-1/133_NE24_SHV-50-3-1/133_NE |
39 |
|
Технический лист |
- | Bulk | Active | SHV | Jack, Female Socket | Crimp | Crimp | 50 Ohms | Panel Mount | Bulkhead - Front Side Nut | RG-58 | Bayonet Lock | 300 MHz | 1 | - | Silver | - | Brass |
|
|
1511-601332.92MM MALE CONNECTOR, EXTENDED |
47 |
|
Технический лист |
- | Tray | Active | 2.92mm | Plug, Male Pin | Solder | Solder | 50 Ohms | Free Hanging (In-Line) | - | 0.047" Semi Rigid | Threaded | 40 GHz | 1 | - | Silver | - | Beryllium Copper |
|
DK-621-0412-PCONN TRIAX JACK STR SOLDER |
41 |
|
Технический лист |
- | Bulk | Active | Triaxial | Jack, Male Pin | Solder | Solder | - | Panel Mount | Bulkhead - Front Side Nut | - | Threaded | - | 1 | - | - | - | - |
|
PLR375C-306CONN TRT PLUG R/A CRIMP |
60 |
|
Технический лист |
370 | Bulk | Active | TRT, Triaxial | Plug, Male Pin (Concentric) | Crimp | Crimp | Non-Constant | Free Hanging (In-Line), Right Angle | - | TRC-50-2, M17/176-00002 | Threaded | 500 MHz | 1 | - | Silver | - | Beryllium Copper |
|
PLR375C-303CONN TRT PLUG R/A CRIMP |
57 |
|
Технический лист |
370 | Bulk | Active | TRT, Triaxial | Plug, Male Pin (Concentric) | Crimp | Crimp | Non-Constant | Free Hanging (In-Line), Right Angle | - | Raychem 7528A5314 | Threaded | 500 MHz | 1 | - | Silver | - | Beryllium Copper |
|
DK-621-0411-PTE circular connector DK-621 series, plug type, designed for secure mating with socket connectors. |
89 |
|
Технический лист |
- | Bulk | Active | Triaxial | Plug, Male Pin | Solder | Solder | - | Free Hanging (In-Line) | - | - | Threaded | - | 1 | - | - | - | - |
|
3811-60019CONN SMPS PLUG STR 50OHM EDGEMNT |
34 |
|
Технический лист |
SMPS | Bulk | Active | SMPS | Plug, Male Pin | Solder | Solder | 50 Ohms | Board Edge, End Launch | - | - | Snap-On | - | 8 | Full Detent | Gold | - | Beryllium Copper |
|
DK-621-0412-SCONN TRIAX JACK STR SOLDER |
26 |
|
Технический лист |
- | Bulk | Active | Triaxial | Jack, Female Socket | Solder | Solder | - | Panel Mount | Bulkhead - Front Side Nut | - | Threaded | - | 1 | - | - | - | - |
|
DK-621-0440-4SCONN TRIAX JACK STR SOLDER |
5,911 |
|
Технический лист |
- | Bulk | Active | Triaxial | Jack, Female Socket | Solder | Solder | - | Panel Mount | Bulkhead - Front Side Nut | - | Bayonet Lock | - | 1 | - | - | - | - |
|
R331018000THT 20 / FEMALE STRAIGHT PLUG |
29 |
|
Технический лист |
- | Box | Active | - | Plug, Male Pin | Solder | Crimp | 50 Ohms | Free Hanging (In-Line) | - | RG-8, 9 | Snap-On | 1 GHz | 1 | - | Silver | - | Brass |
|
MS-156HF(20)CONN COAX SWITCH RCPT STR 50OHM |
2,000 |
|
Технический лист |
MS-156HF | Tape & Reel (TR) | Active | Coaxial Switch - 4mm Plug Dia | Receptacle, Female Socket | Solder | Solder | 50 Ohms | Surface Mount | - | - | Snap-On | 6 GHz | 1 | Internal Switch | Gold | - | Beryllium Copper |
|
MS-180(20)CONN COAX JACK STR 50 OHM SMD |
4,436 |
|
Технический лист |
MS-180 | Tape & Reel (TR) | Active | Coaxial Switch - 2.24mm Plug Dia | Receptacle, Female Socket | Solder | Solder | 50 Ohms | Surface Mount | - | - | Snap-On | 11 GHz | 1 | Internal Switch | Gold | - | Copper Alloy |
.jpg)
|
N.FL-R-SMT-1(10)CONN N.FL RCPT STR 50 OHM SMD |
4,818 |
|
Технический лист |
N.FL | Tape & Reel (TR) | Last Time Buy | U.FL (UMCC) | Receptacle, Male Pin | Solder | Solder | 50 Ohms | Surface Mount | - | - | Snap-On | 6 GHz | 1 | - | Black | - | Brass |
