Настольные, настенные блоки питания переменного тока
| Фото | Номер производителя | Наличие | Количество | Технический лист | Серия | Упаковка | Состояние продукта | Используемая область | Форма | Тип входа | Напряжение - Вход | Напряжение - выход | Ток - выход (макс.) | Мощность (Вт) | Потребляемая мощность без нагрузки | Поляризация | Применение | Эффективность | Рабочая температура | Выходной разъем | Длина шнура | Входной разъем | Особенности | Размер/измерение | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EPS030100-P6RPAC/DC WALL MOUNT ADAPTER 3V 3W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3V | 1A | 3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS033100-P5PAC/DC WALL MNT ADAPTER 3.3V 3.3W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3.3V | 1A | 3.3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS033100-P5RPAC/DC WALL MNT ADAPTER 3.3V 3.3W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3.3V | 1A | 3.3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS033100-P6PAC/DC WALL MNT ADAPTER 3.3V 3.3W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3.3V | 1A | 3.3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS033100-P6RPAC/DC WALL MNT ADAPTER 3.3V 3.3W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3.3V | 1A | 3.3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS045100-P5RPAC/DC WALL MNT ADAPTER 4.5V 4.5W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 4.5V | 1A | 4.5 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS045100-P6PAC/DC WALL MNT ADAPTER 4.5V 4.5W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 4.5V | 1A | 4.5 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS045100-P6RPAC/DC WALL MNT ADAPTER 4.5V 4.5W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 4.5V | 1A | 4.5 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS050100-P6RPAC/DC WALL MOUNT ADAPTER 5V 5W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 5V | 1A | 5 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS060100-P6RPAC/DC WALL MOUNT ADAPTER 6V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 6V | 1A | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS090066-P6RPAC/DC WALL MOUNT ADAPTER 9V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 9V | 660mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS120050-P6PAC/DC WALL MOUNT ADAPTER 12V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 12V | 500mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
EPS120050-P6RPAC/DC WALL MOUNT ADAPTER 12V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 12V | 500mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS150040-P5RPAC/DC WALL MOUNT ADAPTER 15V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 15V | 400mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS150040-P6PAC/DC WALL MOUNT ADAPTER 15V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 15V | 400mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS150040-P6RPAC/DC WALL MOUNT ADAPTER 15V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 15V | 400mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS180033-P5RPAC/DC WALL MOUNT ADAPTER 18V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 18V | 330mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS240025-P5RPAC/DC WALL MOUNT ADAPTER 24V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 24V | 250mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS240025-P6PAC/DC WALL MOUNT ADAPTER 24V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 24V | 250mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
|
|
EPS240025-P6RPAC/DC WALL MOUNT ADAPTER 24V 6W |
0 |
|
Технический лист |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 24V | 250mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus | - |
